| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_020T01_9000006040_45011cztM0_level2.fits | modeM0/AS1A13_020T01_9000006040_45011cztM0_level2_quad_clean.evt |
| Size (bytes) | 599,981,760 | 116,988,480 |
| Size | 572.2 MB | 111.6 MB |
| Events in quadrant A | 6,027,082 | 803,987 |
| Events in quadrant B | 4,167,778 | 830,388 |
| Events in quadrant C | 3,356,592 | 808,815 |
| Events in quadrant D | 8,133,667 | 627,819 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22192 | 2 |
| B | 0 | 16788 | 2 |
| C | 0 | 14396 | 2 |
| D | 0 | 29071 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6768 | 301 | 4.447400% |
| B | 6768 | 251 | 3.708629% |
| C | 6768 | 122 | 1.802600% |
| D | 6768 | 1296 | 19.148936% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7913 | 6769 | 9 | 9 | 0.11% | 0.13% |  |
| B | 7913 | 6769 | 36 | 36 | 0.45% | 0.53% |  |
| C | 7913 | 6769 | 14 | 14 | 0.18% | 0.21% |  |
| D | 7913 | 6769 | 992 | 992 | 12.54% | 14.66% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 2621085 | 15366.43 | 832 | 815 | 170.5 |
| A | 13 | 248 | 153734 | 896.78 | 832 | 815 | 170.5 |
| A | 0 | 243 | 23461 | 132.81 | 832 | 815 | 170.5 |
| B | 0 | 189 | 178788 | 1100.21 | 832 | 806 | 161.8 |
| B | 4 | 171 | 159257 | 979.48 | 832 | 806 | 161.8 |
| B | 5 | 255 | 111493 | 684.22 | 832 | 806 | 161.8 |
| C | 15 | 208 | 81639 | 420.45 | 824 | 831 | 192.2 |
| C | 14 | 254 | 32095 | 162.67 | 824 | 831 | 192.2 |
| C | 12 | 2 | 16399 | 81.0 | 824 | 831 | 192.2 |
| D | 11 | 241 | 1219166 | 6312.95 | 763 | 741 | 193.0 |
| D | 5 | 235 | 1072330 | 5552.15 | 763 | 741 | 193.0 |
| D | 12 | 233 | 1018333 | 5272.38 | 763 | 741 | 193.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
