| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_047T01_9000006068_45310cztM0_level2.fits | modeM0/AS1A13_047T01_9000006068_45310cztM0_level2_quad_clean.evt |
| Size (bytes) | 475,505,280 | 97,254,720 |
| Size | 453.5 MB | 92.7 MB |
| Events in quadrant A | 5,567,649 | 645,576 |
| Events in quadrant B | 3,420,653 | 666,762 |
| Events in quadrant C | 3,383,915 | 637,710 |
| Events in quadrant D | 4,749,164 | 562,302 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20997 | 1 |
| B | 0 | 14505 | 1 |
| C | 0 | 14446 | 1 |
| D | 0 | 18638 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6187 | 196 | 3.167933% |
| B | 6187 | 130 | 2.101180% |
| C | 6188 | 140 | 2.262443% |
| D | 6188 | 351 | 5.672269% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7153 | 6189 | 144 | 144 | 2.01% | 2.33% |  |
| B | 7153 | 6188 | 80 | 80 | 1.12% | 1.29% |  |
| C | 7154 | 6190 | 125 | 125 | 1.75% | 2.02% |  |
| D | 7154 | 6188 | 360 | 360 | 5.03% | 5.82% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 2506015 | 17811.12 | 672 | 658 | 140.7 |
| A | 13 | 248 | 217759 | 1543.42 | 672 | 658 | 140.7 |
| A | 7 | 16 | 161350 | 1142.39 | 672 | 658 | 140.7 |
| B | 0 | 186 | 206419 | 1531.09 | 677 | 659 | 134.4 |
| B | 4 | 158 | 137907 | 1021.28 | 677 | 659 | 134.4 |
| B | 0 | 155 | 100509 | 743.0 | 677 | 659 | 134.4 |
| C | 14 | 254 | 468051 | 2991.56 | 658 | 662 | 156.2 |
| C | 12 | 2 | 139144 | 886.37 | 658 | 662 | 156.2 |
| C | 15 | 208 | 90897 | 577.56 | 658 | 662 | 156.2 |
| D | 1 | 52 | 1190760 | 7224.16 | 643 | 622 | 164.7 |
| D | 13 | 171 | 280980 | 1701.78 | 643 | 622 | 164.7 |
| D | 2 | 249 | 165619 | 1001.54 | 643 | 622 | 164.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
