| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_071T04_9000006110_45561cztM0_level2.fits | modeM0/AS1A13_071T04_9000006110_45561cztM0_level2_quad_clean.evt |
| Size (bytes) | 185,639,040 | 44,012,160 |
| Size | 177.0 MB | 42.0 MB |
| Events in quadrant A | 2,440,798 | 284,337 |
| Events in quadrant B | 1,481,710 | 302,436 |
| Events in quadrant C | 1,207,672 | 299,867 |
| Events in quadrant D | 1,550,006 | 271,154 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8814 | 1 |
| B | 0 | 5889 | 1 |
| C | 0 | 5147 | 1 |
| D | 0 | 6151 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 50 | 0 |
| B | 0 | 50 | 0 |
| C | 0 | 50 | 0 |
| D | 0 | 50 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2439 | 230 | 9.430094% |
| B | 2439 | 153 | 6.273063% |
| C | 2439 | 52 | 2.132021% |
| D | 2438 | 90 | 3.691550% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3634 | 2440 | 35 | 35 | 0.96% | 1.43% |  |
| B | 3634 | 2440 | 56 | 56 | 1.54% | 2.30% |  |
| C | 3634 | 2440 | 1 | 1 | 0.03% | 0.04% |  |
| D | 3633 | 2439 | 29 | 29 | 0.80% | 1.19% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 1085163 | 16969.14 | 304 | 296 | 63.9 |
| A | 13 | 248 | 141228 | 2204.41 | 304 | 296 | 63.9 |
| A | 10 | 248 | 36725 | 569.8 | 304 | 296 | 63.9 |
| B | 5 | 172 | 237640 | 3998.72 | 303 | 294 | 59.4 |
| B | 0 | 183 | 18545 | 307.49 | 303 | 294 | 59.4 |
| B | 12 | 18 | 12165 | 200.0 | 303 | 294 | 59.4 |
| C | 12 | 2 | 12248 | 165.97 | 304 | 305 | 72.0 |
| C | 14 | 254 | 7719 | 103.03 | 304 | 305 | 72.0 |
| C | 13 | 61 | 2045 | 24.18 | 304 | 305 | 72.0 |
| D | 12 | 233 | 131215 | 1727.78 | 302 | 291 | 75.8 |
| D | 5 | 171 | 56564 | 742.63 | 302 | 291 | 75.8 |
| D | 13 | 249 | 46090 | 604.4 | 302 | 291 | 75.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
