| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_071T08_9000006114_45620cztM0_level2.fits | modeM0/AS1A13_071T08_9000006114_45620cztM0_level2_quad_clean.evt |
| Size (bytes) | 678,971,520 | 106,511,040 |
| Size | 647.5 MB | 101.6 MB |
| Events in quadrant A | 5,908,357 | 768,513 |
| Events in quadrant B | 3,881,737 | 769,773 |
| Events in quadrant C | 3,229,228 | 756,802 |
| Events in quadrant D | 11,610,048 | 475,538 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21610 | 1 |
| B | 0 | 15737 | 1 |
| C | 0 | 14103 | 1 |
| D | 0 | 39011 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6511 | 185 | 2.841345% |
| B | 6512 | 310 | 4.760442% |
| C | 6512 | 70 | 1.074939% |
| D | 6512 | 2440 | 37.469287% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7686 | 6512 | 13 | 13 | 0.17% | 0.20% |  |
| B | 7687 | 6512 | 150 | 150 | 1.95% | 2.30% |  |
| C | 7687 | 6512 | 26 | 26 | 0.34% | 0.40% |  |
| D | 7686 | 6512 | 2262 | 2262 | 29.43% | 34.74% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 2883816 | 18314.8 | 766 | 749 | 157.4 |
| A | 13 | 248 | 22800 | 140.08 | 766 | 749 | 157.4 |
| A | 0 | 243 | 20792 | 127.32 | 766 | 749 | 157.4 |
| B | 5 | 172 | 312950 | 2164.63 | 750 | 730 | 144.2 |
| B | 15 | 201 | 286228 | 1979.37 | 750 | 730 | 144.2 |
| B | 4 | 170 | 85562 | 588.14 | 750 | 730 | 144.2 |
| C | 14 | 254 | 229242 | 1320.3 | 745 | 749 | 173.1 |
| C | 0 | 207 | 65115 | 371.92 | 745 | 749 | 173.1 |
| C | 12 | 2 | 18166 | 100.64 | 745 | 749 | 173.1 |
| D | 11 | 241 | 6351174 | 38836.9 | 645 | 625 | 163.5 |
| D | 2 | 249 | 1142240 | 6981.57 | 645 | 625 | 163.5 |
| D | 8 | 129 | 755479 | 4616.32 | 645 | 625 | 163.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
