| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_071T08_9000006114_45623cztM0_level2.fits | modeM0/AS1A13_071T08_9000006114_45623cztM0_level2_quad_clean.evt |
| Size (bytes) | 592,433,280 | 117,138,240 |
| Size | 565.0 MB | 111.7 MB |
| Events in quadrant A | 6,313,423 | 801,065 |
| Events in quadrant B | 4,785,200 | 779,473 |
| Events in quadrant C | 3,553,809 | 780,134 |
| Events in quadrant D | 6,704,075 | 670,811 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23916 | 0 |
| B | 0 | 19282 | 0 |
| C | 0 | 16090 | 0 |
| D | 0 | 25076 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7400 | 165 | 2.229730% |
| B | 7401 | 504 | 6.809891% |
| C | 7401 | 62 | 0.837725% |
| D | 7401 | 626 | 8.458316% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7400 | 7400 | 9 | 9 | 0.12% | 0.12% |  |
| B | 7401 | 7401 | 318 | 318 | 4.30% | 4.30% |  |
| C | 7401 | 7401 | 49 | 49 | 0.66% | 0.66% |  |
| D | 7401 | 7401 | 546 | 546 | 7.38% | 7.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3004276 | 17327.17 | 834 | 815 | 173.3 |
| A | 10 | 255 | 31664 | 177.97 | 834 | 815 | 173.3 |
| A | 0 | 243 | 17015 | 93.46 | 834 | 815 | 173.3 |
| B | 5 | 172 | 883476 | 5531.58 | 813 | 792 | 159.6 |
| B | 3 | 112 | 193563 | 1208.05 | 813 | 792 | 159.6 |
| B | 4 | 170 | 152103 | 948.23 | 813 | 792 | 159.6 |
| C | 14 | 254 | 308689 | 1615.21 | 812 | 817 | 190.6 |
| C | 3 | 233 | 26949 | 137.1 | 812 | 817 | 190.6 |
| C | 0 | 207 | 24138 | 122.35 | 812 | 817 | 190.6 |
| D | 11 | 241 | 1084467 | 5405.81 | 792 | 767 | 200.5 |
| D | 8 | 48 | 750591 | 3740.34 | 792 | 767 | 200.5 |
| D | 8 | 129 | 746370 | 3719.29 | 792 | 767 | 200.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
