| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_028T01_9000006122_45705cztM0_level2.fits | modeM0/AS1A13_028T01_9000006122_45705cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,799,982,720 | 411,050,880 |
| Size | 1.7 GB | 392.0 MB |
| Events in quadrant A | 21,650,855 | 2,761,916 |
| Events in quadrant B | 12,811,092 | 2,854,986 |
| Events in quadrant C | 11,970,427 | 2,761,722 |
| Events in quadrant D | 18,270,009 | 2,350,251 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 510 | 0 |
| B | 0 | 510 | 0 |
| C | 0 | 510 | 0 |
| D | 0 | 510 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 48 | 0 |
| B | 0 | 48 | 0 |
| C | 0 | 48 | 0 |
| D | 0 | 48 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 80541 | 6 |
| B | 0 | 54667 | 5 |
| C | 0 | 52932 | 5 |
| D | 0 | 71202 | 5 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 24953 | 590 | 2.364445% |
| B | 24953 | 505 | 2.023805% |
| C | 24953 | 335 | 1.342524% |
| D | 24953 | 2022 | 8.103234% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 29753 | 24953 | 25 | 25 | 0.08% | 0.10% |  |
| B | 29753 | 24954 | 198 | 198 | 0.67% | 0.79% |  |
| C | 29753 | 24954 | 166 | 166 | 0.56% | 0.67% |  |
| D | 29753 | 24953 | 1683 | 1683 | 5.66% | 6.74% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 10381212 | 17677.0 | 2868 | 2810 | 587.1 |
| A | 13 | 248 | 96362 | 159.34 | 2868 | 2810 | 587.1 |
| A | 13 | 254 | 40230 | 63.74 | 2868 | 2810 | 587.1 |
| B | 5 | 172 | 823966 | 1481.26 | 2855 | 2769 | 554.4 |
| B | 0 | 189 | 153562 | 272.0 | 2855 | 2769 | 554.4 |
| B | 3 | 112 | 109943 | 193.32 | 2855 | 2769 | 554.4 |
| C | 12 | 2 | 613771 | 923.6 | 2840 | 2857 | 661.5 |
| C | 0 | 207 | 112604 | 165.92 | 2840 | 2857 | 661.5 |
| C | 1 | 3 | 88479 | 129.45 | 2840 | 2857 | 661.5 |
| D | 13 | 249 | 2996821 | 4356.67 | 2739 | 2656 | 687.3 |
| D | 1 | 52 | 2565265 | 3728.73 | 2739 | 2656 | 687.3 |
| D | 2 | 249 | 1560981 | 2267.45 | 2739 | 2656 | 687.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
