| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_028T01_9000006122_45709cztM0_level2.fits | modeM0/AS1A13_028T01_9000006122_45709cztM0_level2_quad_clean.evt |
| Size (bytes) | 596,831,040 | 114,649,920 |
| Size | 569.2 MB | 109.3 MB |
| Events in quadrant A | 6,470,521 | 768,797 |
| Events in quadrant B | 4,102,399 | 798,169 |
| Events in quadrant C | 5,315,693 | 763,496 |
| Events in quadrant D | 5,646,235 | 639,645 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23858 | 2 |
| B | 0 | 16753 | 2 |
| C | 0 | 20498 | 2 |
| D | 0 | 21768 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7197 | 364 | 5.057663% |
| B | 7197 | 250 | 3.473670% |
| C | 7197 | 470 | 6.530499% |
| D | 7197 | 912 | 12.671947% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7807 | 7197 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7807 | 7197 | 50 | 50 | 0.64% | 0.69% |  |
| C | 7807 | 7197 | 295 | 295 | 3.78% | 4.10% |  |
| D | 7807 | 7197 | 712 | 712 | 9.12% | 9.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3219967 | 18430.72 | 834 | 813 | 174.7 |
| A | 13 | 254 | 12398 | 66.33 | 834 | 813 | 174.7 |
| A | 3 | 137 | 9493 | 49.7 | 834 | 813 | 174.7 |
| B | 3 | 112 | 377536 | 2246.03 | 837 | 810 | 167.7 |
| B | 5 | 172 | 184189 | 1093.3 | 837 | 810 | 167.7 |
| B | 0 | 183 | 52301 | 306.99 | 837 | 810 | 167.7 |
| C | 9 | 54 | 1904400 | 9870.16 | 816 | 819 | 192.9 |
| C | 1 | 241 | 90155 | 463.21 | 816 | 819 | 192.9 |
| C | 0 | 207 | 60666 | 310.31 | 816 | 819 | 192.9 |
| D | 13 | 249 | 2133106 | 10968.62 | 776 | 750 | 194.4 |
| D | 2 | 249 | 245216 | 1257.51 | 776 | 750 | 194.4 |
| D | 5 | 171 | 68125 | 346.57 | 776 | 750 | 194.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
