| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_183T01_9000006124_45735cztM0_level2.fits | modeM0/AS1T05_183T01_9000006124_45735cztM0_level2_quad_clean.evt |
| Size (bytes) | 556,646,400 | 115,318,080 |
| Size | 530.9 MB | 110.0 MB |
| Events in quadrant A | 6,245,902 | 775,846 |
| Events in quadrant B | 4,644,577 | 792,490 |
| Events in quadrant C | 3,421,930 | 790,469 |
| Events in quadrant D | 5,793,231 | 683,103 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22469 | 2 |
| B | 0 | 17973 | 2 |
| C | 0 | 14248 | 2 |
| D | 0 | 21654 | 4 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6450 | 351 | 5.441860% |
| B | 6450 | 417 | 6.465116% |
| C | 6450 | 139 | 2.155039% |
| D | 6449 | 611 | 9.474337% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7640 | 6451 | 15 | 15 | 0.20% | 0.23% |  |
| B | 7640 | 6451 | 153 | 153 | 2.00% | 2.37% |  |
| C | 7640 | 6451 | 34 | 34 | 0.45% | 0.53% |  |
| D | 7639 | 6450 | 467 | 467 | 6.11% | 7.24% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 2999654 | 18070.97 | 806 | 790 | 165.9 |
| A | 13 | 248 | 85341 | 509.5 | 806 | 790 | 165.9 |
| A | 2 | 79 | 14452 | 82.33 | 806 | 790 | 165.9 |
| B | 3 | 112 | 639980 | 4160.12 | 789 | 766 | 153.7 |
| B | 5 | 172 | 296686 | 1925.9 | 789 | 766 | 153.7 |
| B | 5 | 255 | 165427 | 1071.64 | 789 | 766 | 153.7 |
| C | 14 | 254 | 236751 | 1260.98 | 793 | 800 | 187.1 |
| C | 14 | 96 | 37782 | 197.64 | 793 | 800 | 187.1 |
| C | 12 | 2 | 20968 | 107.78 | 793 | 800 | 187.1 |
| D | 1 | 52 | 1529625 | 7819.92 | 779 | 755 | 195.5 |
| D | 13 | 249 | 861910 | 4404.67 | 779 | 755 | 195.5 |
| D | 2 | 249 | 118262 | 601.03 | 779 | 755 | 195.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
