| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_186T01_9000006130_45842cztM0_level2.fits | modeM0/AS1T05_186T01_9000006130_45842cztM0_level2_quad_clean.evt |
| Size (bytes) | 848,583,360 | 113,402,880 |
| Size | 809.3 MB | 108.1 MB |
| Events in quadrant A | 7,174,622 | 790,637 |
| Events in quadrant B | 11,926,093 | 598,224 |
| Events in quadrant C | 3,430,011 | 822,447 |
| Events in quadrant D | 8,288,054 | 688,196 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25993 | 3 |
| B | 0 | 40819 | 0 |
| C | 0 | 15897 | 0 |
| D | 0 | 29972 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7678 | 428 | 5.574368% |
| B | 7678 | 2697 | 35.126335% |
| C | 7679 | 6 | 0.078135% |
| D | 7679 | 839 | 10.925902% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7678 | 7678 | 246 | 246 | 3.20% | 3.20% |  |
| B | 7678 | 7678 | 1861 | 1861 | 24.24% | 24.24% |  |
| C | 7679 | 7679 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7679 | 7679 | 761 | 761 | 9.91% | 9.91% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3095552 | 16932.19 | 869 | 848 | 182.8 |
| A | 15 | 14 | 490133 | 2677.05 | 869 | 848 | 182.8 |
| A | 14 | 235 | 107278 | 582.32 | 869 | 848 | 182.8 |
| B | 3 | 112 | 8440798 | 54772.07 | 773 | 749 | 154.1 |
| B | 5 | 172 | 109850 | 708.02 | 773 | 749 | 154.1 |
| B | 4 | 171 | 77220 | 496.26 | 773 | 749 | 154.1 |
| C | 3 | 233 | 36550 | 173.38 | 864 | 870 | 205.8 |
| C | 2 | 14 | 24078 | 112.78 | 864 | 870 | 205.8 |
| C | 13 | 61 | 5696 | 23.45 | 864 | 870 | 205.8 |
| D | 1 | 52 | 1281854 | 6045.91 | 834 | 810 | 211.9 |
| D | 11 | 241 | 1246328 | 5878.25 | 834 | 810 | 211.9 |
| D | 12 | 2 | 751045 | 3540.75 | 834 | 810 | 211.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
