| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_080T01_9000006240_46622cztM0_level2.fits | modeM0/AS1A13_080T01_9000006240_46622cztM0_level2_quad_clean.evt |
| Size (bytes) | 570,216,960 | 105,598,080 |
| Size | 543.8 MB | 100.7 MB |
| Events in quadrant A | 5,416,022 | 771,730 |
| Events in quadrant B | 6,847,220 | 560,122 |
| Events in quadrant C | 2,578,537 | 749,587 |
| Events in quadrant D | 5,830,942 | 723,496 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19652 | 1 |
| B | 0 | 24343 | 1 |
| C | 0 | 12289 | 1 |
| D | 0 | 21227 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5611 | 298 | 5.310996% |
| B | 5611 | 1561 | 27.820353% |
| C | 5611 | 39 | 0.695063% |
| D | 5612 | 701 | 12.491091% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6531 | 5612 | 109 | 109 | 1.67% | 1.94% |  |
| B | 6531 | 5612 | 1188 | 1188 | 18.19% | 21.17% |  |
| C | 6531 | 5612 | 10 | 10 | 0.15% | 0.18% |  |
| D | 6532 | 5613 | 715 | 715 | 10.95% | 12.74% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 2642998 | 18542.02 | 662 | 651 | 142.5 |
| A | 9 | 191 | 113226 | 789.97 | 662 | 651 | 142.5 |
| A | 0 | 247 | 30464 | 209.21 | 662 | 651 | 142.5 |
| B | 12 | 3 | 4228520 | 38069.81 | 557 | 542 | 111.1 |
| B | 0 | 189 | 145096 | 1301.6 | 557 | 542 | 111.1 |
| B | 15 | 201 | 127699 | 1144.95 | 557 | 542 | 111.1 |
| C | 14 | 254 | 65900 | 422.97 | 629 | 632 | 154.3 |
| C | 3 | 233 | 20687 | 129.97 | 629 | 632 | 154.3 |
| C | 12 | 250 | 14247 | 88.23 | 629 | 632 | 154.3 |
| D | 12 | 218 | 1714827 | 10010.06 | 644 | 624 | 171.2 |
| D | 1 | 52 | 551828 | 3218.75 | 644 | 624 | 171.2 |
| D | 12 | 128 | 482191 | 2812.1 | 644 | 624 | 171.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
