| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_092T09_9000006258_46721cztM0_level2.fits | modeM0/AS1A13_092T09_9000006258_46721cztM0_level2_quad_clean.evt |
| Size (bytes) | 467,280,000 | 104,978,880 |
| Size | 445.6 MB | 100.1 MB |
| Events in quadrant A | 6,410,804 | 683,766 |
| Events in quadrant B | 3,297,090 | 730,479 |
| Events in quadrant C | 3,365,017 | 693,445 |
| Events in quadrant D | 3,736,148 | 632,148 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23118 | 2 |
| B | 0 | 14037 | 2 |
| C | 0 | 14484 | 2 |
| D | 0 | 15590 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 22 | 0 |
| C | 0 | 22 | 0 |
| D | 0 | 22 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6288 | 294 | 4.675573% |
| B | 6288 | 132 | 2.099237% |
| C | 6287 | 179 | 2.847145% |
| D | 6287 | 188 | 2.990297% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7503 | 6289 | 190 | 190 | 2.53% | 3.02% |  |
| B | 7503 | 6289 | 22 | 22 | 0.29% | 0.35% |  |
| C | 7502 | 6288 | 142 | 142 | 1.89% | 2.26% |  |
| D | 7502 | 6288 | 148 | 148 | 1.97% | 2.35% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 83 | 3368752 | 23403.54 | 696 | 683 | 143.9 |
| A | 9 | 191 | 138870 | 960.21 | 696 | 683 | 143.9 |
| A | 15 | 235 | 90283 | 622.6 | 696 | 683 | 143.9 |
| B | 4 | 171 | 202930 | 1464.05 | 709 | 687 | 138.1 |
| B | 3 | 112 | 118420 | 852.28 | 709 | 687 | 138.1 |
| B | 0 | 183 | 56601 | 404.77 | 709 | 687 | 138.1 |
| C | 12 | 2 | 510261 | 3118.66 | 693 | 699 | 163.4 |
| C | 15 | 208 | 48980 | 295.49 | 693 | 699 | 163.4 |
| C | 14 | 254 | 27027 | 161.13 | 693 | 699 | 163.4 |
| D | 13 | 249 | 388657 | 2218.54 | 688 | 669 | 174.9 |
| D | 7 | 96 | 219969 | 1253.97 | 688 | 669 | 174.9 |
| D | 1 | 52 | 141821 | 807.11 | 688 | 669 | 174.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
