| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T01_9000006440_49786cztM0_level2.fits | modeM0/AS1A13_037T01_9000006440_49786cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,077,073,920 | 62,061,120 |
| Size | 1.0 GB | 59.2 MB |
| Events in quadrant A | 10,326,227 | 492,394 |
| Events in quadrant B | 5,471,557 | 737,410 |
| Events in quadrant C | 6,308,885 | 19,278 |
| Events in quadrant D | 17,178,579 | 99,605 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 36011 | 0 |
| B | 0 | 21306 | 0 |
| C | 0 | 23944 | 0 |
| D | 0 | 56105 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7492 | 3145 | 41.978110% |
| B | 7492 | 637 | 8.502403% |
| C | 7493 | 7493 | 100.000000% |
| D | 7493 | 7438 | 99.265982% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7491 | 7491 | 1825 | 1825 | 24.36% | 24.36% |  |
| B | 7492 | 7492 | 310 | 310 | 4.14% | 4.14% |  |
| C | 7492 | 7492 | 1038 | 1038 | 13.85% | 13.85% |  |
| D | 7492 | 7492 | 6007 | 6007 | 80.18% | 80.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 64 | 1911763 | 12526.94 | 594 | 577 | 152.6 |
| A | 0 | 98 | 1780653 | 11667.57 | 594 | 577 | 152.6 |
| A | 15 | 63 | 1227654 | 8042.92 | 594 | 577 | 152.6 |
| B | 2 | 176 | 1122786 | 6900.98 | 770 | 745 | 162.6 |
| B | 1 | 207 | 470422 | 2888.69 | 770 | 745 | 162.6 |
| B | 4 | 206 | 202444 | 1240.53 | 770 | 745 | 162.6 |
| C | 15 | 147 | 1907579 | 147454.21 | 34 | 33 | 12.9 |
| C | 15 | 148 | 1138248 | 87984.56 | 34 | 33 | 12.9 |
| C | 15 | 164 | 692494 | 53527.56 | 34 | 33 | 12.9 |
| D | 8 | 129 | 6397600 | 99490.92 | 143 | 133 | 64.3 |
| D | 15 | 142 | 3327248 | 51741.99 | 143 | 133 | 64.3 |
| D | 15 | 168 | 2243990 | 34895.59 | 143 | 133 | 64.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
