| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_003T01_9000006442_50150cztM0_level2.fits | modeM0/AS1C09_003T01_9000006442_50150cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,506,300,480 | 49,331,520 |
| Size | 1.4 GB | 47.0 MB |
| Events in quadrant A | 17,690,085 | 77,136 |
| Events in quadrant B | 4,480,435 | 685,977 |
| Events in quadrant C | 14,647,453 | 209,922 |
| Events in quadrant D | 18,389,248 | 20,795 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 57465 | 0 |
| B | 0 | 18233 | 0 |
| C | 0 | 48448 | 1 |
| D | 0 | 59568 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7177 | 6505 | 90.636756% |
| B | 7177 | 226 | 3.148948% |
| C | 7177 | 5086 | 70.865264% |
| D | 7177 | 6991 | 97.408388% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7176 | 7176 | 6149 | 6149 | 85.69% | 85.69% |  |
| B | 7177 | 7177 | 180 | 180 | 2.51% | 2.51% |  |
| C | 7176 | 7176 | 4215 | 4215 | 58.74% | 58.74% |  |
| D | 7176 | 7176 | 6675 | 6675 | 93.02% | 93.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 98 | 9803032 | 92964.64 | 407 | 394 | 105.4 |
| A | 8 | 8 | 5068881 | 48067.68 | 407 | 394 | 105.4 |
| A | 12 | 250 | 335056 | 3173.81 | 407 | 394 | 105.4 |
| B | 5 | 185 | 227236 | 1459.8 | 721 | 695 | 155.2 |
| B | 1 | 255 | 198354 | 1273.68 | 721 | 695 | 155.2 |
| B | 4 | 170 | 197169 | 1266.05 | 721 | 695 | 155.2 |
| C | 15 | 174 | 2184379 | 17731.61 | 440 | 439 | 123.2 |
| C | 15 | 197 | 1726142 | 14011.14 | 440 | 439 | 123.2 |
| C | 4 | 111 | 1122852 | 9112.97 | 440 | 439 | 123.2 |
| D | 15 | 168 | 5187552 | 53428.92 | 313 | 300 | 97.1 |
| D | 7 | 61 | 1972520 | 20313.95 | 313 | 300 | 97.1 |
| D | 15 | 58 | 1058642 | 10900.97 | 313 | 300 | 97.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
