| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T01_9000006450_50797cztM0_level2.fits | modeM0/AS1C07_001T01_9000006450_50797cztM0_level2_quad_clean.evt |
| Size (bytes) | 536,711,040 | 92,856,960 |
| Size | 511.8 MB | 88.6 MB |
| Events in quadrant A | 3,908,854 | 611,254 |
| Events in quadrant B | 3,869,786 | 662,654 |
| Events in quadrant C | 6,662,308 | 565,290 |
| Events in quadrant D | 4,939,218 | 533,607 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15771 | 1 |
| B | 0 | 15838 | 1 |
| C | 0 | 24325 | 1 |
| D | 0 | 19000 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6288 | 219 | 3.482824% |
| B | 6288 | 235 | 3.737277% |
| C | 6288 | 435 | 6.917939% |
| D | 6287 | 392 | 6.235088% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7373 | 6288 | 93 | 93 | 1.26% | 1.48% |  |
| B | 7373 | 6288 | 103 | 103 | 1.40% | 1.64% |  |
| C | 7373 | 6288 | 303 | 303 | 4.11% | 4.82% |  |
| D | 7372 | 6287 | 301 | 301 | 4.08% | 4.79% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 234 | 136056 | 780.12 | 691 | 673 | 173.5 |
| A | 5 | 240 | 131357 | 753.05 | 691 | 673 | 173.5 |
| A | 4 | 3 | 114182 | 654.08 | 691 | 673 | 173.5 |
| B | 4 | 206 | 782276 | 5447.24 | 681 | 658 | 143.5 |
| B | 8 | 128 | 73280 | 506.12 | 681 | 658 | 143.5 |
| B | 0 | 229 | 63667 | 439.12 | 681 | 658 | 143.5 |
| C | 5 | 10 | 2588410 | 14216.2 | 661 | 653 | 182.0 |
| C | 1 | 44 | 320978 | 1759.75 | 661 | 653 | 182.0 |
| C | 13 | 3 | 243899 | 1336.31 | 661 | 653 | 182.0 |
| D | 8 | 48 | 625424 | 3441.37 | 658 | 636 | 181.6 |
| D | 2 | 216 | 428732 | 2357.98 | 658 | 636 | 181.6 |
| D | 2 | 249 | 370460 | 2037.02 | 658 | 636 | 181.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
