| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_090T01_9000006458_51497cztM0_level2.fits | modeM0/AS1A13_090T01_9000006458_51497cztM0_level2_quad_clean.evt |
| Size (bytes) | 641,286,720 | 92,424,960 |
| Size | 611.6 MB | 88.1 MB |
| Events in quadrant A | 5,550,505 | 624,276 |
| Events in quadrant B | 3,955,166 | 683,771 |
| Events in quadrant C | 3,934,798 | 613,690 |
| Events in quadrant D | 9,774,290 | 405,660 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21010 | 2 |
| B | 0 | 16083 | 2 |
| C | 0 | 16344 | 2 |
| D | 0 | 33739 | 9 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6754 | 448 | 6.633106% |
| B | 6755 | 278 | 4.115470% |
| C | 6755 | 204 | 3.019985% |
| D | 6754 | 2390 | 35.386438% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8667 | 6754 | 273 | 273 | 3.15% | 4.04% |  |
| B | 8668 | 6755 | 38 | 38 | 0.44% | 0.56% |  |
| C | 8668 | 6755 | 110 | 110 | 1.27% | 1.63% |  |
| D | 8667 | 6754 | 2269 | 2269 | 26.18% | 33.59% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 3 | 729363 | 4027.73 | 742 | 725 | 180.9 |
| A | 8 | 43 | 597318 | 3297.82 | 742 | 725 | 180.9 |
| A | 12 | 250 | 238538 | 1314.57 | 742 | 725 | 180.9 |
| B | 4 | 81 | 224731 | 1406.06 | 740 | 714 | 159.3 |
| B | 10 | 254 | 155823 | 973.55 | 740 | 714 | 159.3 |
| B | 15 | 52 | 118057 | 736.51 | 740 | 714 | 159.3 |
| C | 12 | 247 | 286120 | 1430.92 | 729 | 723 | 199.4 |
| C | 3 | 233 | 141405 | 705.35 | 729 | 723 | 199.4 |
| C | 13 | 3 | 136403 | 680.27 | 729 | 723 | 199.4 |
| D | 8 | 176 | 3370386 | 19475.12 | 620 | 599 | 173.0 |
| D | 11 | 176 | 2951283 | 17052.99 | 620 | 599 | 173.0 |
| D | 2 | 216 | 642638 | 3710.56 | 620 | 599 | 173.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
