| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T05_9000006460_51602cztM0_level2.fits | modeM0/AS1A13_037T05_9000006460_51602cztM0_level2_quad_clean.evt |
| Size (bytes) | 658,457,280 | 101,856,960 |
| Size | 628.0 MB | 97.1 MB |
| Events in quadrant A | 6,378,245 | 652,856 |
| Events in quadrant B | 4,124,089 | 771,611 |
| Events in quadrant C | 6,612,175 | 560,107 |
| Events in quadrant D | 6,685,664 | 584,505 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24082 | 0 |
| B | 0 | 17152 | 0 |
| C | 0 | 24990 | 0 |
| D | 0 | 25092 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7398 | 763 | 10.313598% |
| B | 7399 | 89 | 1.202865% |
| C | 7399 | 1437 | 19.421543% |
| D | 7399 | 726 | 9.812137% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7398 | 7398 | 356 | 356 | 4.81% | 4.81% |  |
| B | 7399 | 7399 | 36 | 36 | 0.49% | 0.49% |  |
| C | 7399 | 7399 | 1031 | 1031 | 13.93% | 13.93% |  |
| D | 7399 | 7399 | 665 | 665 | 8.99% | 8.99% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 250 | 2101985 | 10995.13 | 765 | 747 | 191.1 |
| A | 12 | 3 | 448537 | 2343.15 | 765 | 747 | 191.1 |
| A | 7 | 206 | 198560 | 1035.09 | 765 | 747 | 191.1 |
| B | 4 | 174 | 153757 | 908.44 | 791 | 766 | 168.4 |
| B | 10 | 44 | 152346 | 900.06 | 791 | 766 | 168.4 |
| B | 5 | 185 | 145549 | 859.7 | 791 | 766 | 168.4 |
| C | 15 | 198 | 3073514 | 16447.37 | 687 | 685 | 186.8 |
| C | 13 | 3 | 381329 | 2037.4 | 687 | 685 | 186.8 |
| C | 1 | 60 | 130754 | 696.2 | 687 | 685 | 186.8 |
| D | 12 | 6 | 959861 | 4743.91 | 729 | 705 | 202.2 |
| D | 7 | 126 | 729639 | 3605.25 | 729 | 705 | 202.2 |
| D | 8 | 176 | 585137 | 2890.56 | 729 | 705 | 202.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
