| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T05_9000006460_51617cztM0_level2.fits | modeM0/AS1A13_037T05_9000006460_51617cztM0_level2_quad_clean.evt |
| Size (bytes) | 635,760,000 | 105,808,320 |
| Size | 606.3 MB | 100.9 MB |
| Events in quadrant A | 5,327,338 | 686,294 |
| Events in quadrant B | 4,943,291 | 770,971 |
| Events in quadrant C | 4,258,142 | 687,381 |
| Events in quadrant D | 8,408,794 | 524,379 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21199 | 0 |
| B | 0 | 19996 | 0 |
| C | 0 | 18342 | 0 |
| D | 0 | 30381 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 154 | 0 |
| B | 0 | 154 | 0 |
| C | 0 | 154 | 0 |
| D | 0 | 154 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7683 | 511 | 6.651048% |
| B | 7684 | 247 | 3.214472% |
| C | 7684 | 164 | 2.134305% |
| D | 7683 | 1609 | 20.942340% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7683 | 7683 | 402 | 402 | 5.23% | 5.23% |  |
| B | 7684 | 7684 | 170 | 170 | 2.21% | 2.21% |  |
| C | 7684 | 7684 | 126 | 126 | 1.64% | 1.64% |  |
| D | 7683 | 7683 | 1576 | 1576 | 20.51% | 20.51% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 250 | 1162737 | 5822.27 | 805 | 787 | 199.6 |
| A | 7 | 206 | 453998 | 2270.94 | 805 | 787 | 199.6 |
| A | 5 | 240 | 93751 | 465.82 | 805 | 787 | 199.6 |
| B | 1 | 207 | 287305 | 1625.43 | 814 | 785 | 176.3 |
| B | 5 | 172 | 223760 | 1264.94 | 814 | 785 | 176.3 |
| B | 1 | 223 | 221742 | 1253.49 | 814 | 785 | 176.3 |
| C | 13 | 3 | 203388 | 920.36 | 799 | 795 | 220.1 |
| C | 15 | 199 | 194678 | 880.79 | 799 | 795 | 220.1 |
| C | 0 | 209 | 161495 | 730.04 | 799 | 795 | 220.1 |
| D | 7 | 222 | 1811018 | 9255.34 | 701 | 677 | 195.6 |
| D | 7 | 60 | 1111056 | 5676.8 | 701 | 677 | 195.6 |
| D | 6 | 42 | 692421 | 3536.53 | 701 | 677 | 195.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
