| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T05_9000006460_51624cztM0_level2.fits | modeM0/AS1A13_037T05_9000006460_51624cztM0_level2_quad_clean.evt |
| Size (bytes) | 785,148,480 | 159,503,040 |
| Size | 748.8 MB | 152.1 MB |
| Events in quadrant A | 7,793,792 | 1,025,977 |
| Events in quadrant B | 6,338,502 | 1,137,534 |
| Events in quadrant C | 5,976,405 | 1,014,230 |
| Events in quadrant D | 8,109,642 | 896,459 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 21 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 30552 | 2 |
| B | 0 | 26215 | 2 |
| C | 0 | 25425 | 2 |
| D | 0 | 31640 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 222 | 0 |
| B | 0 | 222 | 0 |
| C | 0 | 222 | 0 |
| D | 0 | 222 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 10914 | 463 | 4.242258% |
| B | 10914 | 297 | 2.721275% |
| C | 10914 | 221 | 2.024922% |
| D | 10914 | 844 | 7.733187% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 12989 | 10916 | 325 | 325 | 2.50% | 2.98% |  |
| B | 12989 | 10916 | 122 | 122 | 0.94% | 1.12% |  |
| C | 12989 | 10916 | 139 | 139 | 1.07% | 1.27% |  |
| D | 12989 | 10916 | 729 | 729 | 5.61% | 6.68% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 175 | 926719 | 3218.87 | 1187 | 1162 | 287.5 |
| A | 12 | 3 | 800663 | 2780.47 | 1187 | 1162 | 287.5 |
| A | 12 | 250 | 549601 | 1907.34 | 1187 | 1162 | 287.5 |
| B | 10 | 41 | 314902 | 1248.43 | 1181 | 1139 | 251.3 |
| B | 4 | 174 | 190549 | 753.64 | 1181 | 1139 | 251.3 |
| B | 0 | 171 | 182805 | 722.83 | 1181 | 1139 | 251.3 |
| C | 15 | 189 | 357269 | 1102.17 | 1176 | 1166 | 323.1 |
| C | 13 | 3 | 281023 | 866.19 | 1176 | 1166 | 323.1 |
| C | 14 | 245 | 121661 | 372.94 | 1176 | 1166 | 323.1 |
| D | 8 | 176 | 2281038 | 7275.21 | 1135 | 1097 | 313.4 |
| D | 7 | 222 | 307301 | 977.09 | 1135 | 1097 | 313.4 |
| D | 12 | 6 | 235066 | 746.59 | 1135 | 1097 | 313.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
