| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T05_9000006460_51626cztM0_level2.fits | modeM0/AS1A13_037T05_9000006460_51626cztM0_level2_quad_clean.evt |
| Size (bytes) | 503,743,680 | 96,575,040 |
| Size | 480.4 MB | 92.1 MB |
| Events in quadrant A | 4,466,181 | 626,953 |
| Events in quadrant B | 5,211,482 | 647,289 |
| Events in quadrant C | 3,731,179 | 625,730 |
| Events in quadrant D | 4,728,368 | 567,114 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17590 | 1 |
| B | 0 | 19804 | 1 |
| C | 0 | 15546 | 1 |
| D | 0 | 18479 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6561 | 411 | 6.264289% |
| B | 6562 | 688 | 10.484608% |
| C | 6562 | 207 | 3.154526% |
| D | 6562 | 435 | 6.629077% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7646 | 6563 | 234 | 234 | 3.06% | 3.57% |  |
| B | 7647 | 6564 | 511 | 511 | 6.68% | 7.78% |  |
| C | 7647 | 6564 | 64 | 64 | 0.84% | 0.98% |  |
| D | 7647 | 6564 | 369 | 369 | 4.83% | 5.62% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 64 | 993491 | 5604.72 | 731 | 714 | 177.1 |
| A | 12 | 3 | 155729 | 875.13 | 731 | 714 | 177.1 |
| A | 5 | 240 | 89246 | 499.8 | 731 | 714 | 177.1 |
| B | 10 | 44 | 1080155 | 7040.86 | 717 | 692 | 153.3 |
| B | 5 | 172 | 395926 | 2577.94 | 717 | 692 | 153.3 |
| B | 0 | 171 | 124011 | 804.36 | 717 | 692 | 153.3 |
| C | 13 | 3 | 287159 | 1435.58 | 724 | 718 | 199.5 |
| C | 15 | 189 | 168907 | 842.93 | 724 | 718 | 199.5 |
| C | 9 | 38 | 87151 | 433.18 | 724 | 718 | 199.5 |
| D | 8 | 176 | 1009768 | 5121.1 | 709 | 682 | 197.0 |
| D | 3 | 12 | 291169 | 1474.22 | 709 | 682 | 197.0 |
| D | 6 | 42 | 212479 | 1074.87 | 709 | 682 | 197.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
