| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T05_9000006460_51645cztM0_level2.fits | modeM0/AS1A13_037T05_9000006460_51645cztM0_level2_quad_clean.evt |
| Size (bytes) | 676,644,480 | 114,894,720 |
| Size | 645.3 MB | 109.6 MB |
| Events in quadrant A | 7,283,861 | 694,502 |
| Events in quadrant B | 4,755,874 | 826,400 |
| Events in quadrant C | 5,469,973 | 733,677 |
| Events in quadrant D | 6,907,597 | 659,366 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27293 | 0 |
| B | 0 | 19587 | 0 |
| C | 0 | 21871 | 0 |
| D | 0 | 26129 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 162 | 0 |
| B | 0 | 162 | 0 |
| C | 0 | 162 | 0 |
| D | 0 | 162 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8128 | 1013 | 12.463091% |
| B | 8128 | 210 | 2.583661% |
| C | 8128 | 302 | 3.715551% |
| D | 8129 | 658 | 8.094477% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8128 | 8128 | 588 | 588 | 7.23% | 7.23% |  |
| B | 8128 | 8128 | 47 | 47 | 0.58% | 0.58% |  |
| C | 8128 | 8128 | 228 | 228 | 2.81% | 2.81% |  |
| D | 8129 | 8129 | 521 | 521 | 6.41% | 6.41% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 250 | 2053892 | 9613.28 | 868 | 847 | 213.6 |
| A | 7 | 64 | 786064 | 3676.74 | 868 | 847 | 213.6 |
| A | 12 | 3 | 340591 | 1590.83 | 868 | 847 | 213.6 |
| B | 4 | 170 | 216511 | 1123.26 | 895 | 863 | 192.0 |
| B | 10 | 44 | 136939 | 708.79 | 895 | 863 | 192.0 |
| B | 0 | 171 | 121915 | 630.53 | 895 | 863 | 192.0 |
| C | 12 | 254 | 756696 | 3181.23 | 868 | 859 | 237.6 |
| C | 14 | 245 | 475838 | 1999.13 | 868 | 859 | 237.6 |
| C | 13 | 3 | 231505 | 970.76 | 868 | 859 | 237.6 |
| D | 3 | 12 | 1159486 | 4925.05 | 846 | 818 | 235.3 |
| D | 5 | 113 | 494248 | 2097.38 | 846 | 818 | 235.3 |
| D | 8 | 176 | 299784 | 1270.79 | 846 | 818 | 235.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
