| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_011T07_9000006470_52124cztM0_level2.fits | modeM0/AS1C09_011T07_9000006470_52124cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,221,960,960 | 82,978,560 |
| Size | 1.1 GB | 79.1 MB |
| Events in quadrant A | 4,739,516 | 738,615 |
| Events in quadrant B | 4,786,798 | 800,590 |
| Events in quadrant C | 14,205,260 | 403,554 |
| Events in quadrant D | 20,884,579 | 13,963 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 162 | 0 |
| B | 0 | 162 | 0 |
| C | 0 | 162 | 0 |
| D | 0 | 162 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19785 | 1 |
| B | 0 | 19688 | 2 |
| C | 0 | 47767 | 1 |
| D | 0 | 67473 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7986 | 184 | 2.304032% |
| B | 7986 | 165 | 2.066116% |
| C | 7986 | 3974 | 49.762084% |
| D | 7986 | 7882 | 98.697721% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8246 | 7987 | 151 | 151 | 1.83% | 1.89% |  |
| B | 8246 | 7987 | 96 | 96 | 1.16% | 1.20% |  |
| C | 8245 | 7986 | 3152 | 3152 | 38.23% | 39.47% |  |
| D | 8245 | 7985 | 7502 | 7502 | 90.99% | 93.95% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 206 | 339600 | 1613.3 | 838 | 816 | 210.0 |
| A | 4 | 3 | 228118 | 1082.42 | 838 | 816 | 210.0 |
| A | 4 | 249 | 142366 | 674.07 | 838 | 816 | 210.0 |
| B | 10 | 254 | 343929 | 1935.34 | 836 | 805 | 177.3 |
| B | 4 | 81 | 240593 | 1352.49 | 836 | 805 | 177.3 |
| B | 0 | 216 | 146084 | 819.42 | 836 | 805 | 177.3 |
| C | 15 | 224 | 4691254 | 26647.58 | 635 | 628 | 176.0 |
| C | 15 | 248 | 4341471 | 24660.46 | 635 | 628 | 176.0 |
| C | 13 | 3 | 592917 | 3364.81 | 635 | 628 | 176.0 |
| D | 15 | 94 | 13173246 | 166848.7 | 267 | 254 | 79.0 |
| D | 6 | 42 | 5483482 | 69450.39 | 267 | 254 | 79.0 |
| D | 0 | 18 | 386118 | 4887.34 | 267 | 254 | 79.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
