| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_011T07_9000006470_52154cztM0_level2.fits | modeM0/AS1C09_011T07_9000006470_52154cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,200,214,080 | 88,701,120 |
| Size | 1.1 GB | 84.6 MB |
| Events in quadrant A | 6,155,794 | 733,129 |
| Events in quadrant B | 10,870,209 | 560,582 |
| Events in quadrant C | 9,099,576 | 622,024 |
| Events in quadrant D | 17,684,163 | 211,677 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 160 | 0 |
| B | 0 | 160 | 0 |
| C | 0 | 160 | 0 |
| D | 0 | 160 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23966 | 0 |
| B | 0 | 37829 | 5 |
| C | 0 | 32689 | 0 |
| D | 0 | 58121 | 23 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8019 | 152 | 1.895498% |
| B | 8019 | 2953 | 36.825041% |
| C | 8019 | 1472 | 18.356404% |
| D | 8016 | 5861 | 73.116267% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8019 | 8019 | 145 | 145 | 1.81% | 1.81% |  |
| B | 8018 | 8018 | 2216 | 2216 | 27.64% | 27.64% |  |
| C | 8019 | 8019 | 1291 | 1291 | 16.10% | 16.10% |  |
| D | 8019 | 8017 | 5795 | 5795 | 72.27% | 72.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 3 | 1363565 | 6470.85 | 832 | 809 | 210.6 |
| A | 14 | 254 | 328439 | 1555.7 | 832 | 809 | 210.6 |
| A | 3 | 95 | 189278 | 894.92 | 832 | 809 | 210.6 |
| B | 12 | 32 | 6387151 | 44155.09 | 689 | 668 | 144.6 |
| B | 10 | 254 | 890643 | 6153.14 | 689 | 668 | 144.6 |
| B | 4 | 171 | 112419 | 772.63 | 689 | 668 | 144.6 |
| C | 15 | 224 | 2682411 | 12586.38 | 771 | 765 | 213.1 |
| C | 4 | 5 | 896369 | 4203.54 | 771 | 765 | 213.1 |
| C | 15 | 192 | 682485 | 3199.67 | 771 | 765 | 213.1 |
| D | 6 | 42 | 10958215 | 74818.43 | 507 | 484 | 146.5 |
| D | 12 | 3 | 2565192 | 17511.6 | 507 | 484 | 146.5 |
| D | 12 | 17 | 697660 | 4760.26 | 507 | 484 | 146.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
