| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T01_9000006476_52441cztM0_level2.fits | modeM0/AS1A13_037T01_9000006476_52441cztM0_level2_quad_clean.evt |
| Size (bytes) | 691,418,880 | 77,656,320 |
| Size | 659.4 MB | 74.1 MB |
| Events in quadrant A | 2,743,018 | 574,206 |
| Events in quadrant B | 3,842,030 | 601,989 |
| Events in quadrant C | 10,174,837 | 359,214 |
| Events in quadrant D | 8,357,382 | 385,969 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12931 | 1 |
| B | 0 | 15745 | 1 |
| C | 0 | 34499 | 2 |
| D | 0 | 29117 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6153 | 87 | 1.413944% |
| B | 6154 | 256 | 4.159896% |
| C | 6153 | 2465 | 40.061758% |
| D | 6153 | 1651 | 26.832439% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7048 | 6154 | 13 | 13 | 0.18% | 0.21% |  |
| B | 7049 | 6155 | 85 | 85 | 1.21% | 1.38% |  |
| C | 7048 | 6153 | 2201 | 2201 | 31.23% | 35.77% |  |
| D | 7048 | 6153 | 1591 | 1591 | 22.57% | 25.86% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 240 | 77300 | 474.96 | 649 | 631 | 161.4 |
| A | 3 | 14 | 31271 | 189.81 | 649 | 631 | 161.4 |
| A | 15 | 174 | 24141 | 145.64 | 649 | 631 | 161.4 |
| B | 10 | 254 | 451045 | 3300.65 | 633 | 611 | 136.5 |
| B | 0 | 171 | 338118 | 2473.15 | 633 | 611 | 136.5 |
| B | 4 | 171 | 116383 | 848.34 | 633 | 611 | 136.5 |
| C | 15 | 224 | 6032217 | 42529.23 | 510 | 505 | 141.8 |
| C | 15 | 231 | 543825 | 3830.92 | 510 | 505 | 141.8 |
| C | 12 | 254 | 493955 | 3479.29 | 510 | 505 | 141.8 |
| D | 12 | 17 | 1970429 | 13228.16 | 524 | 501 | 148.9 |
| D | 15 | 93 | 1578698 | 10597.66 | 524 | 501 | 148.9 |
| D | 12 | 2 | 1288300 | 8647.63 | 524 | 501 | 148.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
