| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T01_9000006476_52506cztM0_level2.fits | modeM0/AS1A13_037T01_9000006476_52506cztM0_level2_quad_clean.evt |
| Size (bytes) | 4,915,690,560 | 529,142,400 |
| Size | 4.6 GB | 504.6 MB |
| Events in quadrant A | 20,341,571 | 4,013,533 |
| Events in quadrant B | 57,025,412 | 3,238,906 |
| Events in quadrant C | 51,733,103 | 2,898,263 |
| Events in quadrant D | 49,607,934 | 2,962,162 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 90302 | 4 |
| B | 0 | 198369 | 4 |
| C | 0 | 183066 | 4 |
| D | 0 | 176873 | 4 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 856 | 0 |
| B | 0 | 856 | 0 |
| C | 0 | 856 | 0 |
| D | 0 | 856 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 42317 | 547 | 1.292625% |
| B | 42317 | 12342 | 29.165584% |
| C | 42317 | 11216 | 26.504714% |
| D | 42317 | 8602 | 20.327528% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 44337 | 42319 | 110 | 110 | 0.25% | 0.26% |  |
| B | 44336 | 42317 | 10340 | 10340 | 23.32% | 24.43% |  |
| C | 44336 | 42316 | 9744 | 9744 | 21.98% | 23.03% |  |
| D | 44337 | 42318 | 8104 | 8104 | 18.28% | 19.15% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 9 | 597853 | 529.1 | 4576 | 4466 | 1121.5 |
| A | 11 | 3 | 450418 | 397.64 | 4576 | 4466 | 1121.5 |
| A | 3 | 62 | 257016 | 225.19 | 4576 | 4466 | 1121.5 |
| B | 10 | 44 | 20253339 | 23932.11 | 3941 | 3793 | 846.1 |
| B | 10 | 254 | 10329142 | 12203.11 | 3941 | 3793 | 846.1 |
| B | 7 | 0 | 3898422 | 4602.9 | 3941 | 3793 | 846.1 |
| C | 15 | 224 | 26097476 | 24695.09 | 3838 | 3812 | 1056.6 |
| C | 4 | 5 | 2715637 | 2566.48 | 3838 | 3812 | 1056.6 |
| C | 13 | 3 | 2647517 | 2502.01 | 3838 | 3812 | 1056.6 |
| D | 15 | 93 | 13723643 | 12124.91 | 4025 | 3859 | 1131.5 |
| D | 6 | 42 | 11571319 | 10222.78 | 4025 | 3859 | 1131.5 |
| D | 12 | 17 | 1268898 | 1117.98 | 4025 | 3859 | 1131.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
