| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A13_037T01_9000006476_52512cztM0_level2.fits | modeM0/AS1A13_037T01_9000006476_52512cztM0_level2_quad_clean.evt |
| Size (bytes) | 27,216,000 | 2,597,760 |
| Size | 26.0 MB | 2.5 MB |
| Events in quadrant A | 93,987 | 19,316 |
| Events in quadrant B | 392,319 | 4,542 |
| Events in quadrant C | 278,362 | 15,245 |
| Events in quadrant D | 220,331 | 14,538 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 1 |
| B | 0 | 6 | 6 |
| C | 0 | 1 | 1 |
| D | 0 | 7 | 7 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 880 | 376 |
| B | 0 | 2829 | 1512 |
| C | 0 | 1635 | 634 |
| D | 0 | 1571 | 749 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 12 |
| B | 0 | 8 | 4 |
| C | 0 | 15 | 9 |
| D | 0 | 17 | 11 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 252 | 1 | 0.396825% |
| B | 219 | 115 | 52.511416% |
| C | 256 | 29 | 11.328125% |
| D | 245 | 13 | 5.306122% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 279 | 267 | 0 | 0 | 0.00% | 0.00% |  |
| B | 269 | 221 | 112 | 112 | 41.64% | 50.68% |  |
| C | 293 | 276 | 37 | 37 | 12.63% | 13.41% |  |
| D | 283 | 260 | 18 | 18 | 6.36% | 6.92% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 417 | 50.47 | 23 | 23 | 7.8 |
| A | 7 | 160 | 396 | 47.78 | 23 | 23 | 7.8 |
| A | 4 | 3 | 356 | 42.66 | 23 | 23 | 7.8 |
| B | 10 | 44 | 316051 | 62915.29 | 14 | 14 | 5.0 |
| B | 4 | 171 | 7236 | 1437.72 | 14 | 14 | 5.0 |
| B | 10 | 254 | 4719 | 936.65 | 14 | 14 | 5.0 |
| C | 15 | 224 | 131324 | 16766.37 | 22 | 21 | 7.8 |
| C | 13 | 3 | 31957 | 4077.98 | 22 | 21 | 7.8 |
| C | 15 | 233 | 27990 | 3571.42 | 22 | 21 | 7.8 |
| D | 15 | 93 | 45870 | 6031.92 | 21 | 20 | 7.6 |
| D | 7 | 96 | 36589 | 4810.93 | 21 | 20 | 7.6 |
| D | 2 | 153 | 28001 | 3681.12 | 21 | 20 | 7.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
