| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_011T06_9000006478_52549cztM0_level2.fits | modeM0/AS1C09_011T06_9000006478_52549cztM0_level2_quad_clean.evt |
| Size (bytes) | 2,423,747,520 | 212,829,120 |
| Size | 2.3 GB | 203.0 MB |
| Events in quadrant A | 9,745,389 | 1,711,933 |
| Events in quadrant B | 16,849,314 | 1,706,723 |
| Events in quadrant C | 21,377,863 | 1,255,883 |
| Events in quadrant D | 40,293,592 | 469,942 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 42391 | 2 |
| B | 0 | 63135 | 2 |
| C | 0 | 76788 | 2 |
| D | 0 | 132482 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 380 | 0 |
| B | 0 | 380 | 0 |
| C | 0 | 380 | 0 |
| D | 0 | 380 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 18842 | 386 | 2.048615% |
| B | 18843 | 1653 | 8.772488% |
| C | 18843 | 4607 | 24.449398% |
| D | 18843 | 13865 | 73.581701% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19732 | 18845 | 165 | 165 | 0.84% | 0.88% |  |
| B | 19733 | 18846 | 868 | 868 | 4.40% | 4.61% |  |
| C | 19733 | 18846 | 3444 | 3444 | 17.45% | 18.27% |  |
| D | 19733 | 18844 | 12087 | 12087 | 61.25% | 64.14% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 249 | 319455 | 639.08 | 1993 | 1943 | 496.8 |
| A | 4 | 159 | 279133 | 557.92 | 1993 | 1943 | 496.8 |
| A | 4 | 61 | 223537 | 446.02 | 1993 | 1943 | 496.8 |
| B | 4 | 170 | 2497449 | 6198.0 | 1911 | 1844 | 402.6 |
| B | 10 | 44 | 1834507 | 4551.54 | 1911 | 1844 | 402.6 |
| B | 10 | 254 | 1096836 | 2719.48 | 1911 | 1844 | 402.6 |
| C | 15 | 224 | 6696016 | 14325.71 | 1690 | 1672 | 467.3 |
| C | 13 | 3 | 1855451 | 3967.04 | 1690 | 1672 | 467.3 |
| C | 15 | 147 | 1453973 | 3107.88 | 1690 | 1672 | 467.3 |
| D | 6 | 42 | 23928084 | 74076.78 | 1108 | 1054 | 323.0 |
| D | 7 | 126 | 2384255 | 7378.26 | 1108 | 1054 | 323.0 |
| D | 11 | 176 | 2192473 | 6784.51 | 1108 | 1054 | 323.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
