| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_011T06_9000006478_52550cztM0_level2.fits | modeM0/AS1C09_011T06_9000006478_52550cztM0_level2_quad_clean.evt |
| Size (bytes) | 809,585,280 | 79,450,560 |
| Size | 772.1 MB | 75.8 MB |
| Events in quadrant A | 4,220,567 | 578,062 |
| Events in quadrant B | 6,245,922 | 601,692 |
| Events in quadrant C | 6,906,734 | 502,766 |
| Events in quadrant D | 12,100,101 | 275,905 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17170 | 1 |
| B | 0 | 22953 | 1 |
| C | 0 | 24988 | 1 |
| D | 0 | 40393 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6403 | 405 | 6.325160% |
| B | 6403 | 604 | 9.433078% |
| C | 6403 | 1044 | 16.304857% |
| D | 6403 | 3486 | 54.443230% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7163 | 6404 | 314 | 314 | 4.38% | 4.90% |  |
| B | 7163 | 6404 | 283 | 283 | 3.95% | 4.42% |  |
| C | 7163 | 6404 | 914 | 914 | 12.76% | 14.27% |  |
| D | 7162 | 6403 | 3004 | 3004 | 41.94% | 46.92% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 494604 | 3000.22 | 659 | 642 | 164.6 |
| A | 4 | 159 | 323026 | 1958.09 | 659 | 642 | 164.6 |
| A | 4 | 249 | 276643 | 1676.37 | 659 | 642 | 164.6 |
| B | 4 | 170 | 2203253 | 15749.79 | 653 | 630 | 139.9 |
| B | 10 | 254 | 403395 | 2879.96 | 653 | 630 | 139.9 |
| B | 10 | 44 | 279104 | 1991.22 | 653 | 630 | 139.9 |
| C | 15 | 224 | 1861471 | 10750.47 | 623 | 616 | 173.1 |
| C | 15 | 248 | 1047181 | 6046.18 | 623 | 616 | 173.1 |
| C | 13 | 3 | 812229 | 4688.82 | 623 | 616 | 173.1 |
| D | 6 | 42 | 5938251 | 41791.91 | 489 | 466 | 142.1 |
| D | 8 | 176 | 1640642 | 11544.05 | 489 | 466 | 142.1 |
| D | 11 | 176 | 663317 | 4665.34 | 489 | 466 | 142.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
