| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_011T06_9000006478_52600cztM0_level2.fits | modeM0/AS1C09_011T06_9000006478_52600cztM0_level2_quad_clean.evt |
| Size (bytes) | 770,754,240 | 79,171,200 |
| Size | 735.0 MB | 75.5 MB |
| Events in quadrant A | 3,256,935 | 592,750 |
| Events in quadrant B | 4,063,072 | 640,849 |
| Events in quadrant C | 6,437,275 | 530,291 |
| Events in quadrant D | 14,281,517 | 190,089 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14503 | 1 |
| B | 0 | 16611 | 1 |
| C | 0 | 23648 | 1 |
| D | 0 | 46824 | 8 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6348 | 155 | 2.441714% |
| B | 6349 | 144 | 2.268074% |
| C | 6349 | 717 | 11.293117% |
| D | 6348 | 4508 | 71.014493% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7473 | 6349 | 118 | 118 | 1.58% | 1.86% |  |
| B | 7474 | 6350 | 62 | 62 | 0.83% | 0.98% |  |
| C | 7474 | 6350 | 660 | 660 | 8.83% | 10.39% |  |
| D | 7473 | 6349 | 4621 | 4621 | 61.84% | 72.78% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 249 | 373367 | 2332.38 | 639 | 624 | 159.8 |
| A | 3 | 28 | 63853 | 395.65 | 639 | 624 | 159.8 |
| A | 5 | 243 | 52147 | 322.4 | 639 | 624 | 159.8 |
| B | 10 | 254 | 541674 | 3963.36 | 645 | 623 | 136.5 |
| B | 10 | 128 | 344686 | 2520.36 | 645 | 623 | 136.5 |
| B | 4 | 171 | 77827 | 565.54 | 645 | 623 | 136.5 |
| C | 15 | 248 | 2793642 | 16290.76 | 612 | 607 | 171.4 |
| C | 1 | 44 | 432310 | 2517.97 | 612 | 607 | 171.4 |
| C | 15 | 192 | 252052 | 1466.59 | 612 | 607 | 171.4 |
| D | 12 | 16 | 7440316 | 62111.08 | 399 | 379 | 119.8 |
| D | 8 | 176 | 2334911 | 19489.45 | 399 | 379 | 119.8 |
| D | 15 | 125 | 703598 | 5870.71 | 399 | 379 | 119.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
