| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_011T06_9000006478_52618cztM0_level2.fits | modeM0/AS1C09_011T06_9000006478_52618cztM0_level2_quad_clean.evt |
| Size (bytes) | 964,126,080 | 75,695,040 |
| Size | 919.5 MB | 72.2 MB |
| Events in quadrant A | 3,506,994 | 641,781 |
| Events in quadrant B | 6,659,182 | 671,084 |
| Events in quadrant C | 16,610,347 | 1,630 |
| Events in quadrant D | 8,366,721 | 486,397 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15738 | 0 |
| B | 0 | 24668 | 0 |
| C | 0 | 54066 | 0 |
| D | 0 | 29815 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7043 | 85 | 1.206872% |
| B | 7043 | 331 | 4.699702% |
| C | 7043 | 7030 | 99.815420% |
| D | 7044 | 1282 | 18.199886% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7043 | 7043 | 76 | 76 | 1.08% | 1.08% |  |
| B | 7043 | 7043 | 186 | 186 | 2.64% | 2.64% |  |
| C | 7042 | 7042 | 5484 | 5484 | 77.88% | 77.88% |  |
| D | 7044 | 7044 | 1130 | 1130 | 16.04% | 16.04% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 46 | 335439 | 1857.39 | 713 | 694 | 180.2 |
| A | 7 | 190 | 85913 | 472.85 | 713 | 694 | 180.2 |
| A | 12 | 3 | 64124 | 351.95 | 713 | 694 | 180.2 |
| B | 10 | 254 | 2840348 | 18959.07 | 699 | 676 | 149.8 |
| B | 8 | 234 | 256053 | 1705.02 | 699 | 676 | 149.8 |
| B | 10 | 247 | 192353 | 1279.73 | 699 | 676 | 149.8 |
| C | 15 | 248 | 16223570 | 730094.87 | 74 | 73 | 22.2 |
| C | 12 | 254 | 53857 | 2420.4 | 74 | 73 | 22.2 |
| C | 14 | 254 | 6612 | 294.27 | 74 | 73 | 22.2 |
| D | 2 | 62 | 1676509 | 9369.55 | 627 | 598 | 178.9 |
| D | 8 | 176 | 1087151 | 6074.62 | 627 | 598 | 178.9 |
| D | 2 | 37 | 1056520 | 5903.37 | 627 | 598 | 178.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
