| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_011T06_9000006478_52629cztM0_level2.fits | modeM0/AS1C09_011T06_9000006478_52629cztM0_level2_quad_clean.evt |
| Size (bytes) | 944,435,520 | 72,662,400 |
| Size | 900.7 MB | 69.3 MB |
| Events in quadrant A | 3,771,590 | 611,246 |
| Events in quadrant B | 11,835,222 | 326,369 |
| Events in quadrant C | 12,972,721 | 285,082 |
| Events in quadrant D | 5,885,611 | 529,705 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15708 | 2 |
| B | 0 | 39514 | 2 |
| C | 0 | 42884 | 5 |
| D | 0 | 21914 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6410 | 68 | 1.060842% |
| B | 6410 | 3706 | 57.815913% |
| C | 6409 | 3721 | 58.058980% |
| D | 6409 | 390 | 6.085193% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7535 | 6411 | 53 | 53 | 0.70% | 0.83% |  |
| B | 7535 | 6411 | 2933 | 2933 | 38.93% | 45.75% |  |
| C | 7534 | 6410 | 3354 | 3354 | 44.52% | 52.32% |  |
| D | 7534 | 6410 | 391 | 391 | 5.19% | 6.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 14 | 563237 | 3414.48 | 656 | 641 | 164.8 |
| A | 8 | 246 | 96450 | 581.48 | 656 | 641 | 164.8 |
| A | 8 | 9 | 95616 | 576.42 | 656 | 641 | 164.8 |
| B | 10 | 128 | 4801767 | 43950.95 | 520 | 503 | 109.2 |
| B | 10 | 254 | 4000491 | 36616.04 | 520 | 503 | 109.2 |
| B | 5 | 185 | 384109 | 3511.54 | 520 | 503 | 109.2 |
| C | 15 | 248 | 9783526 | 76540.37 | 462 | 457 | 127.8 |
| C | 13 | 3 | 992606 | 7762.33 | 462 | 457 | 127.8 |
| C | 1 | 44 | 59425 | 461.35 | 462 | 457 | 127.8 |
| D | 2 | 62 | 1219527 | 6755.17 | 625 | 596 | 180.4 |
| D | 1 | 7 | 382390 | 2115.86 | 625 | 596 | 180.4 |
| D | 6 | 42 | 284690 | 1574.41 | 625 | 596 | 180.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
