| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_011T07_9000006480_52644cztM0_level2.fits | modeM0/AS1C09_011T07_9000006480_52644cztM0_level2_quad_clean.evt |
| Size (bytes) | 95,451,840 | 7,459,200 |
| Size | 91.0 MB | 7.1 MB |
| Events in quadrant A | 742,022 | 49,188 |
| Events in quadrant B | 478,338 | 65,831 |
| Events in quadrant C | 1,598,099 | 1,021 |
| Events in quadrant D | 658,716 | 54,816 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2673 | 0 |
| B | 0 | 1895 | 0 |
| C | 0 | 5205 | 0 |
| D | 0 | 2429 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 681 | 168 | 24.669604% |
| B | 681 | 10 | 1.468429% |
| C | 681 | 660 | 96.916300% |
| D | 681 | 50 | 7.342144% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 680 | 680 | 154 | 154 | 22.65% | 22.65% |  |
| B | 681 | 681 | 7 | 7 | 1.03% | 1.03% |  |
| C | 680 | 680 | 602 | 602 | 88.53% | 88.53% |  |
| D | 681 | 681 | 54 | 54 | 7.93% | 7.93% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 9 | 429805 | 27222.59 | 54 | 52 | 15.8 |
| A | 4 | 249 | 27972 | 1768.59 | 54 | 52 | 15.8 |
| A | 3 | 14 | 15527 | 980.26 | 54 | 52 | 15.8 |
| B | 10 | 128 | 143683 | 9008.76 | 64 | 62 | 15.9 |
| B | 5 | 185 | 41802 | 2618.18 | 64 | 62 | 15.9 |
| B | 7 | 252 | 6137 | 381.06 | 64 | 62 | 15.9 |
| C | 15 | 178 | 1344970 | 212098.56 | 16 | 16 | 6.3 |
| C | 15 | 248 | 136914 | 21588.75 | 16 | 16 | 6.3 |
| C | 2 | 239 | 26585 | 4189.92 | 16 | 16 | 6.3 |
| D | 8 | 176 | 228946 | 11971.0 | 60 | 57 | 19.1 |
| D | 6 | 42 | 48616 | 2539.66 | 60 | 57 | 19.1 |
| D | 15 | 93 | 40335 | 2106.56 | 60 | 57 | 19.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
