| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C09_011T07_9000006480_52684cztM0_level2.fits | modeM0/AS1C09_011T07_9000006480_52684cztM0_level2_quad_clean.evt |
| Size (bytes) | 328,504,320 | 30,666,240 |
| Size | 313.3 MB | 29.2 MB |
| Events in quadrant A | 1,326,629 | 237,899 |
| Events in quadrant B | 2,712,755 | 230,167 |
| Events in quadrant C | 5,433,547 | 91,747 |
| Events in quadrant D | 2,493,424 | 190,579 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 50 | 0 |
| B | 0 | 50 | 0 |
| C | 0 | 50 | 0 |
| D | 0 | 50 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5594 | 0 |
| B | 0 | 9807 | 0 |
| C | 0 | 17828 | 0 |
| D | 0 | 9077 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2478 | 25 | 1.008878% |
| B | 2479 | 267 | 10.770472% |
| C | 2479 | 1604 | 64.703509% |
| D | 2479 | 295 | 11.899960% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2478 | 2478 | 23 | 23 | 0.93% | 0.93% |  |
| B | 2479 | 2479 | 186 | 186 | 7.50% | 7.50% |  |
| C | 2479 | 2479 | 1624 | 1624 | 65.51% | 65.51% |  |
| D | 2479 | 2479 | 300 | 300 | 12.10% | 12.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 14 | 156130 | 2462.13 | 241 | 235 | 63.3 |
| A | 5 | 241 | 92222 | 1452.8 | 241 | 235 | 63.3 |
| A | 7 | 206 | 26017 | 407.19 | 241 | 235 | 63.3 |
| B | 10 | 128 | 830820 | 16448.94 | 230 | 222 | 50.5 |
| B | 12 | 32 | 372273 | 7368.0 | 230 | 222 | 50.5 |
| B | 4 | 171 | 136526 | 2699.33 | 230 | 222 | 50.5 |
| C | 15 | 248 | 2937776 | 60435.21 | 169 | 166 | 48.6 |
| C | 14 | 96 | 1261726 | 25953.97 | 169 | 166 | 48.6 |
| C | 12 | 252 | 218621 | 4494.26 | 169 | 166 | 48.6 |
| D | 1 | 7 | 550784 | 8408.8 | 225 | 215 | 65.5 |
| D | 8 | 176 | 493114 | 7528.01 | 225 | 215 | 65.5 |
| D | 12 | 33 | 162160 | 2473.37 | 225 | 215 | 65.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
