| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_123T01_9000000024_00231cztM0_level2.evt | modeM0/AS1P01_123T01_9000000024_00231cztM0_level2_quad_clean.evt |
| Size (bytes) | 946,497,600 | 84,885,120 |
| Size | 902.7 MB | 81.0 MB |
| Events in quadrant A | 6,480,926 | 553,847 |
| Events in quadrant B | 6,794,087 | 559,052 |
| Events in quadrant C | 6,153,232 | 565,339 |
| Events in quadrant D | 8,879,360 | 514,671 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 110 | 0 |
| B | 0 | 110 | 0 |
| C | 0 | 110 | 0 |
| D | 0 | 110 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23089 | 2 |
| B | 0 | 23978 | 1 |
| C | 0 | 22068 | 1 |
| D | 0 | 30255 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5392 | 12 | 0.222552% |
| B | 5392 | 31 | 0.574926% |
| C | 5392 | 1 | 0.018546% |
| D | 5392 | 481 | 8.920623% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7096 | 5393 | 162 | 162 | 2.28% | 3.00% |  |
| B | 7096 | 5393 | 168 | 168 | 2.37% | 3.12% |  |
| C | 7096 | 5393 | 59 | 59 | 0.83% | 1.09% |  |
| D | 7096 | 5393 | 1309 | 1309 | 18.45% | 24.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 250 | 56863 | 154.02 | 1634 | 1613 | 358.7 |
| A | 12 | 150 | 41412 | 110.94 | 1634 | 1613 | 358.7 |
| A | 0 | 96 | 18565 | 47.26 | 1634 | 1613 | 358.7 |
| B | 7 | 220 | 210179 | 548.29 | 1646 | 1648 | 380.3 |
| B | 5 | 46 | 134710 | 349.86 | 1646 | 1648 | 380.3 |
| B | 8 | 6 | 50616 | 128.75 | 1646 | 1648 | 380.3 |
| C | 1 | 1 | 97163 | 223.69 | 1540 | 1595 | 427.2 |
| C | 9 | 54 | 4330 | 6.4 | 1540 | 1595 | 427.2 |
| C | 2 | 192 | 4038 | 5.72 | 1540 | 1595 | 427.2 |
| D | 1 | 4 | 1877529 | 3667.74 | 1514 | 1512 | 511.5 |
| D | 13 | 46 | 258195 | 501.83 | 1514 | 1512 | 511.5 |
| D | 1 | 5 | 142428 | 275.5 | 1514 | 1512 | 511.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
