| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_123T01_9000000024_00232cztM0_level2.evt | modeM0/AS1P01_123T01_9000000024_00232cztM0_level2_quad_clean.evt |
| Size (bytes) | 840,072,960 | 78,693,120 |
| Size | 801.2 MB | 75.0 MB |
| Events in quadrant A | 5,890,539 | 504,859 |
| Events in quadrant B | 6,112,162 | 510,136 |
| Events in quadrant C | 5,608,929 | 524,377 |
| Events in quadrant D | 7,494,266 | 489,003 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21106 | 2 |
| B | 0 | 21743 | 1 |
| C | 0 | 20271 | 1 |
| D | 0 | 25870 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5061 | 6 | 0.118554% |
| B | 5061 | 7 | 0.138313% |
| C | 5061 | 1 | 0.019759% |
| D | 5061 | 198 | 3.912270% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6797 | 5062 | 104 | 104 | 1.53% | 2.05% |  |
| B | 6797 | 5062 | 125 | 125 | 1.84% | 2.47% |  |
| C | 6797 | 5062 | 43 | 43 | 0.63% | 0.85% |  |
| D | 6797 | 5062 | 827 | 827 | 12.17% | 16.34% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 250 | 26374 | 74.14 | 1498 | 1479 | 335.8 |
| A | 15 | 17 | 21339 | 59.15 | 1498 | 1479 | 335.8 |
| A | 13 | 34 | 12811 | 33.75 | 1498 | 1479 | 335.8 |
| B | 7 | 220 | 170134 | 476.92 | 1517 | 1524 | 353.5 |
| B | 5 | 46 | 67568 | 186.81 | 1517 | 1524 | 353.5 |
| B | 4 | 184 | 29321 | 78.63 | 1517 | 1524 | 353.5 |
| C | 1 | 1 | 64044 | 159.81 | 1411 | 1467 | 391.6 |
| C | 9 | 231 | 3530 | 5.27 | 1411 | 1467 | 391.6 |
| C | 10 | 69 | 3500 | 5.19 | 1411 | 1467 | 391.6 |
| D | 1 | 4 | 1495610 | 3600.22 | 1377 | 1395 | 415.0 |
| D | 1 | 5 | 154930 | 369.93 | 1377 | 1395 | 415.0 |
| D | 2 | 170 | 104452 | 248.31 | 1377 | 1395 | 415.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
