| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_123T01_9000000024_00235cztM0_level2.evt | modeM0/AS1P01_123T01_9000000024_00235cztM0_level2_quad_clean.evt |
| Size (bytes) | 821,439,360 | 77,232,960 |
| Size | 783.4 MB | 73.7 MB |
| Events in quadrant A | 5,986,202 | 486,343 |
| Events in quadrant B | 6,263,109 | 493,454 |
| Events in quadrant C | 5,508,652 | 506,141 |
| Events in quadrant D | 6,763,591 | 478,419 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21614 | 2 |
| B | 0 | 22390 | 1 |
| C | 0 | 20199 | 1 |
| D | 0 | 23922 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5351 | 5 | 0.093440% |
| B | 5351 | 7 | 0.130817% |
| C | 5351 | 1 | 0.018688% |
| D | 5351 | 107 | 1.999626% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7087 | 5352 | 91 | 91 | 1.28% | 1.70% |  |
| B | 7087 | 5352 | 119 | 119 | 1.68% | 2.22% |  |
| C | 7087 | 5352 | 28 | 28 | 0.40% | 0.52% |  |
| D | 7087 | 5352 | 434 | 434 | 6.12% | 8.11% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 13444 | 34.67 | 1536 | 1520 | 343.9 |
| A | 15 | 17 | 11875 | 30.11 | 1536 | 1520 | 343.9 |
| A | 12 | 150 | 9092 | 22.02 | 1536 | 1520 | 343.9 |
| B | 7 | 220 | 110421 | 300.36 | 1551 | 1563 | 362.4 |
| B | 5 | 46 | 87507 | 237.13 | 1551 | 1563 | 362.4 |
| B | 0 | 85 | 86710 | 234.93 | 1551 | 1563 | 362.4 |
| C | 4 | 253 | 9136 | 19.78 | 1396 | 1443 | 388.8 |
| C | 10 | 21 | 9028 | 19.51 | 1396 | 1443 | 388.8 |
| C | 9 | 68 | 7903 | 16.61 | 1396 | 1443 | 388.8 |
| D | 1 | 4 | 1225248 | 3092.34 | 1359 | 1384 | 395.8 |
| D | 10 | 154 | 103853 | 258.91 | 1359 | 1384 | 395.8 |
| D | 1 | 5 | 82248 | 204.32 | 1359 | 1384 | 395.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
