| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_126T03_9000000032_00284cztM0_level2.evt | modeM0/AS1P01_126T03_9000000032_00284cztM0_level2_quad_clean.evt |
| Size (bytes) | 948,049,920 | 16,603,200 |
| Size | 904.1 MB | 15.8 MB |
| Events in quadrant A | 7,612,527 | 22,813 |
| Events in quadrant B | 7,353,588 | 23,677 |
| Events in quadrant C | 6,738,339 | 22,720 |
| Events in quadrant D | 6,617,197 | 21,345 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26771 | 3 |
| B | 0 | 25993 | 2 |
| C | 0 | 24239 | 2 |
| D | 0 | 23856 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5885 | 15 | 0.254885% |
| B | 5885 | 8 | 0.135939% |
| C | 5885 | 29 | 0.492778% |
| D | 5885 | 15 | 0.254885% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7590 | 5886 | 252 | 252 | 3.32% | 4.28% |  |
| B | 7590 | 5886 | 142 | 142 | 1.87% | 2.41% |  |
| C | 7590 | 5886 | 148 | 148 | 1.95% | 2.51% |  |
| D | 7590 | 5886 | 94 | 94 | 1.24% | 1.60% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 250 | 127501 | 303.23 | 1875 | 1858 | 414.3 |
| A | 12 | 149 | 94670 | 224.0 | 1875 | 1858 | 414.3 |
| A | 15 | 127 | 65282 | 153.07 | 1875 | 1858 | 414.3 |
| B | 7 | 220 | 112040 | 252.4 | 1836 | 1845 | 436.6 |
| B | 0 | 183 | 98877 | 222.25 | 1836 | 1845 | 436.6 |
| B | 0 | 151 | 39005 | 85.11 | 1836 | 1845 | 436.6 |
| C | 1 | 1 | 136118 | 288.47 | 1652 | 1708 | 465.9 |
| C | 3 | 159 | 86647 | 182.3 | 1652 | 1708 | 465.9 |
| C | 1 | 192 | 12819 | 23.85 | 1652 | 1708 | 465.9 |
| D | 1 | 5 | 100721 | 192.69 | 1626 | 1687 | 513.9 |
| D | 13 | 117 | 84395 | 160.93 | 1626 | 1687 | 513.9 |
| D | 13 | 7 | 63164 | 119.62 | 1626 | 1687 | 513.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
