| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_044T01_9000000072_00463cztM0_level2.evt | modeM0/AS1P01_044T01_9000000072_00463cztM0_level2_quad_clean.evt |
| Size (bytes) | 853,770,240 | 59,310,720 |
| Size | 814.2 MB | 56.6 MB |
| Events in quadrant A | 6,365,795 | 366,108 |
| Events in quadrant B | 6,988,206 | 361,663 |
| Events in quadrant C | 5,628,959 | 371,004 |
| Events in quadrant D | 6,546,054 | 350,410 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29 | 0 |
| B | 0 | 29 | 0 |
| C | 0 | 29 | 0 |
| D | 0 | 30 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22644 | 203 |
| B | 0 | 24518 | 192 |
| C | 0 | 20429 | 175 |
| D | 0 | 23082 | 150 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 100 | 0 |
| B | 0 | 100 | 0 |
| C | 0 | 100 | 0 |
| D | 0 | 100 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4935 | 8 | 0.162107% |
| B | 4936 | 378 | 7.658023% |
| C | 4941 | 21 | 0.425015% |
| D | 4940 | 41 | 0.829960% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7127 | 4966 | 204 | 204 | 2.86% | 4.11% |  |
| B | 7127 | 4964 | 560 | 560 | 7.86% | 11.28% |  |
| C | 7127 | 4969 | 66 | 66 | 0.93% | 1.33% |  |
| D | 7127 | 4964 | 258 | 258 | 3.62% | 5.20% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 238 | 113684 | 324.78 | 1578 | 1569 | 345.2 |
| A | 0 | 69 | 92398 | 263.11 | 1578 | 1569 | 345.2 |
| A | 13 | 160 | 25165 | 68.35 | 1578 | 1569 | 345.2 |
| B | 15 | 223 | 976552 | 2728.16 | 1541 | 1556 | 357.4 |
| B | 11 | 51 | 36238 | 97.04 | 1541 | 1556 | 357.4 |
| B | 7 | 221 | 18931 | 48.62 | 1541 | 1556 | 357.4 |
| C | 3 | 159 | 129039 | 332.66 | 1392 | 1439 | 383.6 |
| C | 5 | 249 | 15599 | 36.92 | 1392 | 1439 | 383.6 |
| C | 10 | 237 | 7633 | 16.15 | 1392 | 1439 | 383.6 |
| D | 7 | 85 | 320782 | 705.04 | 1385 | 1426 | 453.0 |
| D | 12 | 237 | 162854 | 356.38 | 1385 | 1426 | 453.0 |
| D | 1 | 4 | 151941 | 332.29 | 1385 | 1426 | 453.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
