| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_124T01_9000000094_00659cztM0_level2.evt | modeM0/AS1P01_124T01_9000000094_00659cztM0_level2_quad_clean.evt |
| Size (bytes) | 841,665,600 | 63,233,280 |
| Size | 802.7 MB | 60.3 MB |
| Events in quadrant A | 6,170,105 | 394,940 |
| Events in quadrant B | 6,095,097 | 395,639 |
| Events in quadrant C | 5,718,623 | 388,152 |
| Events in quadrant D | 7,158,384 | 369,378 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 25 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22042 | 2 |
| B | 0 | 21824 | 2 |
| C | 0 | 20735 | 2 |
| D | 0 | 25023 | 4 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5231 | 12 | 0.229402% |
| B | 5231 | 6 | 0.114701% |
| C | 5231 | 33 | 0.630855% |
| D | 5230 | 301 | 5.755258% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7388 | 5232 | 124 | 124 | 1.68% | 2.37% |  |
| B | 7388 | 5232 | 80 | 80 | 1.08% | 1.53% |  |
| C | 7388 | 5232 | 85 | 85 | 1.15% | 1.62% |  |
| D | 7387 | 5231 | 699 | 699 | 9.46% | 13.36% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 69 | 76900 | 222.57 | 1534 | 1515 | 338.7 |
| A | 14 | 79 | 40383 | 114.75 | 1534 | 1515 | 338.7 |
| A | 12 | 236 | 37538 | 106.35 | 1534 | 1515 | 338.7 |
| B | 5 | 6 | 83104 | 224.84 | 1534 | 1542 | 362.7 |
| B | 5 | 191 | 49566 | 132.39 | 1534 | 1542 | 362.7 |
| B | 0 | 220 | 27367 | 71.19 | 1534 | 1542 | 362.7 |
| C | 9 | 52 | 123541 | 310.3 | 1404 | 1457 | 393.4 |
| C | 3 | 159 | 62966 | 156.34 | 1404 | 1457 | 393.4 |
| C | 15 | 241 | 8749 | 18.53 | 1404 | 1457 | 393.4 |
| D | 1 | 4 | 708245 | 1684.73 | 1348 | 1400 | 419.6 |
| D | 13 | 221 | 295023 | 699.84 | 1348 | 1400 | 419.6 |
| D | 2 | 152 | 273620 | 648.82 | 1348 | 1400 | 419.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
