| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_010T01_9000000108_00740cztM0_level2.evt | modeM0/AS1P01_010T01_9000000108_00740cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,132,035,840 | 93,582,720 |
| Size | 1.1 GB | 89.2 MB |
| Events in quadrant A | 7,783,338 | 603,822 |
| Events in quadrant B | 9,007,675 | 607,162 |
| Events in quadrant C | 7,804,995 | 592,406 |
| Events in quadrant D | 9,237,038 | 556,247 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27967 | 0 |
| B | 0 | 31589 | 0 |
| C | 0 | 28030 | 0 |
| D | 0 | 32302 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6806 | 15 | 0.220394% |
| B | 6806 | 47 | 0.690567% |
| C | 6807 | 11 | 0.161598% |
| D | 6806 | 353 | 5.186600% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7701 | 6807 | 146 | 146 | 1.90% | 2.14% |  |
| B | 7701 | 6807 | 456 | 456 | 5.92% | 6.70% |  |
| C | 7702 | 6808 | 148 | 148 | 1.92% | 2.17% |  |
| D | 7701 | 6807 | 969 | 969 | 12.58% | 14.24% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 230 | 19376 | 35.84 | 2019 | 2034 | 483.8 |
| A | 15 | 171 | 10385 | 17.26 | 2019 | 2034 | 483.8 |
| A | 11 | 79 | 9988 | 16.44 | 2019 | 2034 | 483.8 |
| B | 8 | 38 | 684744 | 1365.02 | 2136 | 2144 | 500.1 |
| B | 7 | 221 | 101921 | 199.53 | 2136 | 2144 | 500.1 |
| B | 0 | 220 | 35688 | 67.08 | 2136 | 2144 | 500.1 |
| C | 15 | 241 | 44904 | 78.99 | 1961 | 2023 | 542.9 |
| C | 3 | 111 | 32029 | 55.27 | 1961 | 2023 | 542.9 |
| C | 9 | 52 | 29116 | 49.91 | 1961 | 2023 | 542.9 |
| D | 13 | 25 | 1628693 | 2854.54 | 1842 | 1908 | 569.9 |
| D | 1 | 4 | 180788 | 313.88 | 1842 | 1908 | 569.9 |
| D | 6 | 226 | 132601 | 229.33 | 1842 | 1908 | 569.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
