| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_010T01_9000000108_00756cztM0_level2.evt | modeM0/AS1P01_010T01_9000000108_00756cztM0_level2_quad_clean.evt |
| Size (bytes) | 2,133,570,240 | 172,713,600 |
| Size | 2.0 GB | 164.7 MB |
| Events in quadrant A | 15,364,515 | 1,104,456 |
| Events in quadrant B | 17,307,268 | 1,113,527 |
| Events in quadrant C | 14,990,286 | 1,096,951 |
| Events in quadrant D | 16,133,936 | 1,056,146 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 252 | 0 |
| B | 0 | 252 | 0 |
| C | 0 | 252 | 0 |
| D | 0 | 252 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 54466 | 0 |
| B | 0 | 60248 | 0 |
| C | 0 | 53334 | 0 |
| D | 0 | 56871 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 12436 | 352 | 2.830492% |
| B | 12436 | 374 | 3.007398% |
| C | 12436 | 163 | 1.310711% |
| D | 12435 | 293 | 2.356253% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 13206 | 12438 | 815 | 815 | 6.17% | 6.55% |  |
| B | 13206 | 12438 | 1445 | 1445 | 10.94% | 11.62% |  |
| C | 13206 | 12438 | 613 | 613 | 4.64% | 4.93% |  |
| D | 13205 | 12437 | 1307 | 1307 | 9.90% | 10.51% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 117 | 471981 | 500.51 | 3864 | 3886 | 935.2 |
| A | 15 | 17 | 25835 | 23.47 | 3864 | 3886 | 935.2 |
| A | 14 | 79 | 23668 | 21.15 | 3864 | 3886 | 935.2 |
| B | 8 | 38 | 1446622 | 1505.61 | 4061 | 4075 | 958.1 |
| B | 7 | 221 | 206876 | 211.67 | 4061 | 4075 | 958.1 |
| B | 8 | 234 | 82346 | 81.69 | 4061 | 4075 | 958.1 |
| C | 5 | 234 | 121054 | 111.59 | 3735 | 3868 | 1050.1 |
| C | 15 | 241 | 114402 | 105.26 | 3735 | 3868 | 1050.1 |
| C | 3 | 111 | 61288 | 54.68 | 3735 | 3868 | 1050.1 |
| D | 13 | 25 | 1988570 | 1769.42 | 3613 | 3739 | 1121.7 |
| D | 6 | 226 | 289361 | 254.62 | 3613 | 3739 | 1121.7 |
| D | 1 | 4 | 142105 | 123.35 | 3613 | 3739 | 1121.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
