| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_010T01_9000000112_00798cztM0_level2.evt | modeM0/AS1P01_010T01_9000000112_00798cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,074,421,440 | 106,297,920 |
| Size | 1.0 GB | 101.4 MB |
| Events in quadrant A | 8,113,459 | 690,027 |
| Events in quadrant B | 8,607,829 | 698,000 |
| Events in quadrant C | 7,983,997 | 674,656 |
| Events in quadrant D | 7,363,274 | 663,443 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29139 | 0 |
| B | 0 | 30579 | 0 |
| C | 0 | 28721 | 0 |
| D | 0 | 26948 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7074 | 33 | 0.466497% |
| B | 7074 | 23 | 0.325134% |
| C | 7074 | 3 | 0.042409% |
| D | 7074 | 20 | 0.282725% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7929 | 7075 | 218 | 218 | 2.75% | 3.08% |  |
| B | 7929 | 7075 | 279 | 279 | 3.52% | 3.94% |  |
| C | 7929 | 7075 | 151 | 151 | 1.90% | 2.13% |  |
| D | 7929 | 7075 | 110 | 110 | 1.39% | 1.55% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 233 | 138290 | 271.98 | 2077 | 2092 | 500.8 |
| A | 11 | 79 | 9107 | 14.01 | 2077 | 2092 | 500.8 |
| A | 3 | 111 | 6282 | 8.37 | 2077 | 2092 | 500.8 |
| B | 15 | 22 | 71555 | 134.51 | 2201 | 2203 | 515.6 |
| B | 5 | 191 | 52808 | 98.15 | 2201 | 2203 | 515.6 |
| B | 0 | 23 | 31828 | 57.46 | 2201 | 2203 | 515.6 |
| C | 15 | 241 | 53152 | 92.31 | 2003 | 2072 | 553.4 |
| C | 10 | 207 | 34892 | 59.31 | 2003 | 2072 | 553.4 |
| C | 3 | 111 | 29322 | 49.24 | 2003 | 2072 | 553.4 |
| D | 1 | 4 | 106818 | 178.95 | 1902 | 1966 | 585.9 |
| D | 13 | 25 | 50955 | 83.61 | 1902 | 1966 | 585.9 |
| D | 13 | 164 | 28208 | 44.79 | 1902 | 1966 | 585.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
