| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_156T01_9000000114_00837cztM0_level2.evt | modeM0/AS1P01_156T01_9000000114_00837cztM0_level2_quad_clean.evt |
| Size (bytes) | 808,352,640 | 64,630,080 |
| Size | 770.9 MB | 61.6 MB |
| Events in quadrant A | 5,906,499 | 407,533 |
| Events in quadrant B | 6,292,708 | 407,191 |
| Events in quadrant C | 5,785,550 | 405,266 |
| Events in quadrant D | 6,165,519 | 388,067 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21038 | 0 |
| B | 0 | 22229 | 0 |
| C | 0 | 20716 | 0 |
| D | 0 | 21900 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4973 | 36 | 0.723909% |
| B | 4973 | 57 | 1.146189% |
| C | 4973 | 30 | 0.603258% |
| D | 4973 | 250 | 5.027147% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4972 | 4972 | 186 | 186 | 3.74% | 3.74% |  |
| B | 4972 | 4972 | 251 | 251 | 5.05% | 5.05% |  |
| C | 4972 | 4972 | 137 | 137 | 2.76% | 2.76% |  |
| D | 4973 | 4973 | 465 | 465 | 9.35% | 9.35% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 127 | 113139 | 307.55 | 1506 | 1518 | 362.9 |
| A | 15 | 171 | 8076 | 18.07 | 1506 | 1518 | 362.9 |
| A | 12 | 251 | 7591 | 16.73 | 1506 | 1518 | 362.9 |
| B | 5 | 65 | 147386 | 397.25 | 1582 | 1592 | 367.0 |
| B | 0 | 220 | 42236 | 110.74 | 1582 | 1592 | 367.0 |
| B | 2 | 2 | 29227 | 75.3 | 1582 | 1592 | 367.0 |
| C | 8 | 208 | 58256 | 142.39 | 1442 | 1498 | 398.6 |
| C | 3 | 111 | 19678 | 45.61 | 1442 | 1498 | 398.6 |
| C | 9 | 83 | 18093 | 41.63 | 1442 | 1498 | 398.6 |
| D | 7 | 70 | 836061 | 1997.34 | 1361 | 1406 | 417.9 |
| D | 13 | 200 | 169084 | 401.25 | 1361 | 1406 | 417.9 |
| D | 13 | 169 | 22370 | 50.17 | 1361 | 1406 | 417.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
