| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_156T01_9000000118_00847cztM0_level2.evt | modeM0/AS1P01_156T01_9000000118_00847cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,168,096,320 | 69,920,640 |
| Size | 1.1 GB | 66.7 MB |
| Events in quadrant A | 8,872,314 | 408,534 |
| Events in quadrant B | 9,408,172 | 408,382 |
| Events in quadrant C | 8,515,348 | 405,403 |
| Events in quadrant D | 8,104,165 | 394,127 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31461 | 0 |
| B | 0 | 33061 | 0 |
| C | 0 | 30422 | 0 |
| D | 0 | 29126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7179 | 58 | 0.807912% |
| B | 7179 | 87 | 1.211868% |
| C | 7180 | 55 | 0.766017% |
| D | 7180 | 54 | 0.752089% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7824 | 7179 | 243 | 243 | 3.11% | 3.38% |  |
| B | 7824 | 7179 | 335 | 335 | 4.28% | 4.67% |  |
| C | 7825 | 7180 | 184 | 184 | 2.35% | 2.56% |  |
| D | 7825 | 7180 | 147 | 147 | 1.88% | 2.05% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 171 | 46750 | 79.67 | 2296 | 2316 | 557.8 |
| A | 15 | 17 | 14529 | 21.9 | 2296 | 2316 | 557.8 |
| A | 3 | 111 | 7307 | 8.95 | 2296 | 2316 | 557.8 |
| B | 0 | 184 | 79251 | 138.02 | 2359 | 2376 | 557.0 |
| B | 0 | 220 | 61699 | 106.5 | 2359 | 2376 | 557.0 |
| B | 8 | 38 | 56253 | 96.73 | 2359 | 2376 | 557.0 |
| C | 15 | 241 | 41852 | 65.74 | 2153 | 2238 | 602.6 |
| C | 3 | 111 | 26709 | 40.61 | 2153 | 2238 | 602.6 |
| C | 3 | 79 | 14517 | 20.38 | 2153 | 2238 | 602.6 |
| D | 1 | 4 | 88994 | 131.14 | 2118 | 2193 | 661.9 |
| D | 13 | 200 | 39918 | 57.0 | 2118 | 2193 | 661.9 |
| D | 13 | 13 | 31332 | 44.02 | 2118 | 2193 | 661.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
