| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_156T01_9000000118_00852cztM0_level2.evt | modeM0/AS1P01_156T01_9000000118_00852cztM0_level2_quad_clean.evt |
| Size (bytes) | 823,913,280 | 66,084,480 |
| Size | 785.7 MB | 63.0 MB |
| Events in quadrant A | 6,193,449 | 414,750 |
| Events in quadrant B | 6,879,372 | 415,462 |
| Events in quadrant C | 5,978,832 | 417,924 |
| Events in quadrant D | 5,566,967 | 400,647 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21990 | 0 |
| B | 0 | 24028 | 0 |
| C | 0 | 21314 | 0 |
| D | 0 | 20160 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5025 | 52 | 1.034826% |
| B | 5025 | 61 | 1.213930% |
| C | 5025 | 44 | 0.875622% |
| D | 5025 | 42 | 0.835821% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5039 | 5025 | 259 | 259 | 5.14% | 5.15% |  |
| B | 5039 | 5025 | 495 | 495 | 9.82% | 9.85% |  |
| C | 5039 | 5025 | 193 | 193 | 3.83% | 3.84% |  |
| D | 5039 | 5025 | 151 | 151 | 3.00% | 3.00% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 231 | 151100 | 395.99 | 1567 | 1588 | 377.6 |
| A | 15 | 171 | 12941 | 30.07 | 1567 | 1588 | 377.6 |
| A | 15 | 233 | 10305 | 23.09 | 1567 | 1588 | 377.6 |
| B | 5 | 191 | 420621 | 1095.19 | 1641 | 1654 | 382.6 |
| B | 8 | 38 | 71990 | 183.86 | 1641 | 1654 | 382.6 |
| B | 0 | 184 | 41913 | 105.24 | 1641 | 1654 | 382.6 |
| C | 15 | 241 | 27371 | 61.63 | 1512 | 1568 | 418.7 |
| C | 3 | 111 | 19245 | 42.22 | 1512 | 1568 | 418.7 |
| C | 3 | 79 | 11051 | 22.65 | 1512 | 1568 | 418.7 |
| D | 10 | 85 | 78818 | 173.27 | 1452 | 1511 | 446.2 |
| D | 1 | 4 | 35261 | 75.64 | 1452 | 1511 | 446.2 |
| D | 2 | 170 | 18379 | 37.81 | 1452 | 1511 | 446.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
