| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_161T03_9000000178_00896cztM0_level2.evt | modeM0/AS1P01_161T03_9000000178_00896cztM0_level2_quad_clean.evt |
| Size (bytes) | 701,631,360 | 42,825,600 |
| Size | 669.1 MB | 40.8 MB |
| Events in quadrant A | 5,044,635 | 255,305 |
| Events in quadrant B | 5,841,320 | 250,493 |
| Events in quadrant C | 5,470,747 | 246,509 |
| Events in quadrant D | 4,606,670 | 241,796 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 88 | 0 |
| B | 0 | 88 | 0 |
| C | 0 | 88 | 0 |
| D | 0 | 88 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18032 | 0 |
| B | 0 | 20441 | 0 |
| C | 0 | 19329 | 0 |
| D | 0 | 16748 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4290 | 44 | 1.025641% |
| B | 4290 | 104 | 2.424242% |
| C | 4291 | 32 | 0.745747% |
| D | 4291 | 27 | 0.629224% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4290 | 4290 | 165 | 165 | 3.85% | 3.85% |  |
| B | 4290 | 4290 | 371 | 371 | 8.65% | 8.65% |  |
| C | 4291 | 4291 | 159 | 159 | 3.71% | 3.71% |  |
| D | 4291 | 4291 | 98 | 98 | 2.28% | 2.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 170 | 113594 | 366.97 | 1276 | 1285 | 306.0 |
| A | 15 | 233 | 30500 | 95.46 | 1276 | 1285 | 306.0 |
| A | 11 | 79 | 5460 | 13.64 | 1276 | 1285 | 306.0 |
| B | 3 | 0 | 521183 | 1664.95 | 1344 | 1353 | 312.2 |
| B | 8 | 38 | 63962 | 200.53 | 1344 | 1353 | 312.2 |
| B | 7 | 221 | 47668 | 148.34 | 1344 | 1353 | 312.2 |
| C | 9 | 83 | 570383 | 1641.27 | 1242 | 1291 | 346.7 |
| C | 3 | 111 | 17830 | 47.7 | 1242 | 1291 | 346.7 |
| C | 3 | 79 | 12780 | 33.13 | 1242 | 1291 | 346.7 |
| D | 1 | 4 | 75229 | 202.76 | 1188 | 1231 | 364.9 |
| D | 7 | 0 | 30532 | 80.29 | 1188 | 1231 | 364.9 |
| D | 7 | 143 | 26705 | 69.8 | 1188 | 1231 | 364.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
