| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_998T01_9000000188_00988cztM0_level2.evt | modeM0/AS1P01_998T01_9000000188_00988cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,312,833,600 | 111,064,320 |
| Size | 1.2 GB | 105.9 MB |
| Events in quadrant A | 8,831,970 | 738,065 |
| Events in quadrant B | 9,584,342 | 737,502 |
| Events in quadrant C | 9,107,085 | 717,780 |
| Events in quadrant D | 11,744,342 | 652,255 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31566 | 0 |
| B | 0 | 33739 | 0 |
| C | 0 | 32313 | 0 |
| D | 0 | 40253 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7444 | 8 | 0.107469% |
| B | 7443 | 39 | 0.523982% |
| C | 7443 | 8 | 0.107484% |
| D | 7443 | 854 | 11.473868% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7695 | 7446 | 270 | 270 | 3.51% | 3.63% |  |
| B | 7694 | 7445 | 450 | 450 | 5.85% | 6.04% |  |
| C | 7694 | 7445 | 300 | 300 | 3.90% | 4.03% |  |
| D | 7694 | 7445 | 1711 | 1711 | 22.24% | 22.98% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 233 | 13847 | 20.8 | 2296 | 2316 | 554.5 |
| A | 11 | 79 | 9744 | 13.4 | 2296 | 2316 | 554.5 |
| A | 12 | 189 | 8219 | 10.65 | 2296 | 2316 | 554.5 |
| B | 8 | 234 | 151893 | 263.85 | 2404 | 2410 | 566.6 |
| B | 0 | 220 | 73626 | 125.7 | 2404 | 2410 | 566.6 |
| B | 5 | 249 | 58074 | 98.25 | 2404 | 2410 | 566.6 |
| C | 15 | 241 | 351874 | 565.73 | 2220 | 2300 | 617.9 |
| C | 3 | 79 | 35002 | 52.92 | 2220 | 2300 | 617.9 |
| C | 3 | 111 | 34096 | 51.46 | 2220 | 2300 | 617.9 |
| D | 12 | 188 | 2301187 | 3719.28 | 2001 | 2071 | 618.2 |
| D | 1 | 4 | 1513721 | 2445.4 | 2001 | 2071 | 618.2 |
| D | 1 | 83 | 290400 | 466.43 | 2001 | 2071 | 618.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
