| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_998T02_9000000190_01032cztM0_level2.evt | modeM0/AS1P01_998T02_9000000190_01032cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,297,382,400 | 130,587,840 |
| Size | 1.2 GB | 124.5 MB |
| Events in quadrant A | 9,346,555 | 867,001 |
| Events in quadrant B | 9,782,848 | 875,227 |
| Events in quadrant C | 11,165,320 | 837,309 |
| Events in quadrant D | 8,485,612 | 838,022 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 33239 | 3 |
| B | 0 | 34530 | 3 |
| C | 0 | 38662 | 3 |
| D | 0 | 30747 | 4 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 158 | 0 |
| B | 0 | 158 | 0 |
| C | 0 | 158 | 0 |
| D | 0 | 158 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7726 | 26 | 0.336526% |
| B | 7726 | 33 | 0.427129% |
| C | 7726 | 245 | 3.171111% |
| D | 7725 | 9 | 0.116505% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7935 | 7728 | 390 | 390 | 4.91% | 5.05% |  |
| B | 7935 | 7728 | 482 | 482 | 6.07% | 6.24% |  |
| C | 7935 | 7728 | 1211 | 1211 | 15.26% | 15.67% |  |
| D | 7934 | 7727 | 259 | 259 | 3.26% | 3.35% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 32 | 141731 | 241.66 | 2393 | 2402 | 576.5 |
| A | 12 | 189 | 17788 | 26.69 | 2393 | 2402 | 576.5 |
| A | 11 | 79 | 8857 | 11.2 | 2393 | 2402 | 576.5 |
| B | 15 | 22 | 73802 | 120.61 | 2504 | 2508 | 591.1 |
| B | 0 | 220 | 49932 | 80.23 | 2504 | 2508 | 591.1 |
| B | 5 | 249 | 42604 | 67.83 | 2504 | 2508 | 591.1 |
| C | 8 | 208 | 1737687 | 2720.57 | 2296 | 2383 | 637.8 |
| C | 15 | 241 | 357178 | 556.24 | 2296 | 2383 | 637.8 |
| C | 3 | 79 | 36194 | 53.01 | 2296 | 2383 | 637.8 |
| D | 10 | 125 | 84678 | 118.62 | 2239 | 2317 | 694.3 |
| D | 13 | 73 | 12999 | 15.38 | 2239 | 2317 | 694.3 |
| D | 9 | 65 | 12833 | 15.15 | 2239 | 2317 | 694.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
