| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_998T02_9000000190_01054cztM0_level2.evt | modeM0/AS1P01_998T02_9000000190_01054cztM0_level2_quad_clean.evt |
| Size (bytes) | 940,265,280 | 104,060,160 |
| Size | 896.7 MB | 99.2 MB |
| Events in quadrant A | 7,015,780 | 696,163 |
| Events in quadrant B | 7,274,479 | 704,286 |
| Events in quadrant C | 6,955,779 | 670,814 |
| Events in quadrant D | 6,833,738 | 663,630 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25118 | 1 |
| B | 0 | 25853 | 1 |
| C | 0 | 24938 | 2 |
| D | 0 | 24561 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5963 | 37 | 0.620493% |
| B | 5963 | 34 | 0.570183% |
| C | 5963 | 39 | 0.654033% |
| D | 5963 | 27 | 0.452792% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7073 | 5964 | 159 | 159 | 2.25% | 2.67% |  |
| B | 7073 | 5964 | 174 | 174 | 2.46% | 2.92% |  |
| C | 7073 | 5964 | 151 | 151 | 2.13% | 2.53% |  |
| D | 7073 | 5964 | 316 | 316 | 4.47% | 5.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 253 | 63504 | 142.35 | 1808 | 1822 | 433.3 |
| A | 15 | 127 | 13477 | 26.9 | 1808 | 1822 | 433.3 |
| A | 11 | 79 | 5777 | 9.13 | 1808 | 1822 | 433.3 |
| B | 15 | 22 | 33973 | 72.38 | 1873 | 1885 | 443.3 |
| B | 8 | 234 | 33670 | 71.7 | 1873 | 1885 | 443.3 |
| B | 5 | 249 | 26480 | 55.48 | 1873 | 1885 | 443.3 |
| C | 15 | 241 | 307189 | 658.89 | 1673 | 1725 | 463.6 |
| C | 9 | 52 | 68924 | 144.95 | 1673 | 1725 | 463.6 |
| C | 3 | 111 | 23081 | 46.06 | 1673 | 1725 | 463.6 |
| D | 12 | 22 | 605283 | 1190.02 | 1644 | 1700 | 507.2 |
| D | 13 | 73 | 36803 | 69.21 | 1644 | 1700 | 507.2 |
| D | 10 | 125 | 19891 | 35.87 | 1644 | 1700 | 507.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
