| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_998T02_9000000190_01079cztM0_level2.evt | modeM0/AS1P01_998T02_9000000190_01079cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,095,543,360 | 118,854,720 |
| Size | 1.0 GB | 113.3 MB |
| Events in quadrant A | 8,169,341 | 781,250 |
| Events in quadrant B | 8,679,647 | 789,852 |
| Events in quadrant C | 8,391,182 | 770,898 |
| Events in quadrant D | 7,463,298 | 759,380 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29417 | 2 |
| B | 0 | 30896 | 2 |
| C | 0 | 29996 | 2 |
| D | 0 | 27320 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7162 | 1 | 0.013963% |
| B | 7162 | 6 | 0.083775% |
| C | 7163 | 1 | 0.013961% |
| D | 7163 | 22 | 0.307134% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7942 | 7163 | 112 | 112 | 1.41% | 1.56% |  |
| B | 7942 | 7163 | 165 | 165 | 2.08% | 2.30% |  |
| C | 7943 | 7164 | 129 | 129 | 1.62% | 1.80% |  |
| D | 7943 | 7164 | 108 | 108 | 1.36% | 1.51% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 243 | 19351 | 33.66 | 2122 | 2138 | 511.3 |
| A | 11 | 79 | 10121 | 15.61 | 2122 | 2138 | 511.3 |
| A | 0 | 253 | 8534 | 12.51 | 2122 | 2138 | 511.3 |
| B | 15 | 22 | 60551 | 110.13 | 2245 | 2255 | 529.3 |
| B | 5 | 191 | 25737 | 44.36 | 2245 | 2255 | 529.3 |
| B | 3 | 204 | 19318 | 32.24 | 2245 | 2255 | 529.3 |
| C | 15 | 241 | 363559 | 639.53 | 2034 | 2101 | 565.2 |
| C | 9 | 52 | 30700 | 50.6 | 2034 | 2101 | 565.2 |
| C | 3 | 111 | 27254 | 44.5 | 2034 | 2101 | 565.2 |
| D | 2 | 216 | 151496 | 249.58 | 1933 | 2006 | 599.0 |
| D | 9 | 64 | 25491 | 39.21 | 1933 | 2006 | 599.0 |
| D | 10 | 125 | 17909 | 26.55 | 1933 | 2006 | 599.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
