| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1P01_997T02_9000000212_01108cztM0_level2.evt | modeM0/AS1P01_997T02_9000000212_01108cztM0_level2_quad_clean.evt |
| Size (bytes) | 523,120,320 | 51,477,120 |
| Size | 498.9 MB | 49.1 MB |
| Events in quadrant A | 3,821,206 | 328,784 |
| Events in quadrant B | 4,058,220 | 329,298 |
| Events in quadrant C | 4,106,097 | 325,740 |
| Events in quadrant D | 3,616,883 | 320,937 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13947 | 67 |
| B | 0 | 14674 | 61 |
| C | 0 | 14780 | 61 |
| D | 0 | 13390 | 60 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 76 | 0 |
| B | 0 | 76 | 0 |
| C | 0 | 76 | 0 |
| D | 0 | 76 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3574 | 3 | 0.083940% |
| B | 3576 | 4 | 0.111857% |
| C | 3576 | 2 | 0.055928% |
| D | 3574 | 33 | 0.923335% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4240 | 3576 | 46 | 46 | 1.08% | 1.29% |  |
| B | 4243 | 3579 | 65 | 65 | 1.53% | 1.82% |  |
| C | 4242 | 3578 | 69 | 69 | 1.63% | 1.93% |  |
| D | 4242 | 3576 | 86 | 86 | 2.03% | 2.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 147 | 6139 | 21.39 | 993 | 1003 | 240.1 |
| A | 11 | 79 | 4448 | 14.35 | 993 | 1003 | 240.1 |
| A | 12 | 243 | 3575 | 10.71 | 993 | 1003 | 240.1 |
| B | 4 | 187 | 11259 | 41.08 | 1059 | 1065 | 248.2 |
| B | 2 | 32 | 11257 | 41.07 | 1059 | 1065 | 248.2 |
| B | 5 | 249 | 5388 | 17.42 | 1059 | 1065 | 248.2 |
| C | 15 | 241 | 176356 | 651.19 | 960 | 993 | 269.3 |
| C | 10 | 207 | 142700 | 526.21 | 960 | 993 | 269.3 |
| C | 3 | 111 | 13429 | 46.18 | 960 | 993 | 269.3 |
| D | 2 | 216 | 94188 | 349.95 | 922 | 937 | 266.5 |
| D | 10 | 125 | 19109 | 68.2 | 922 | 937 | 266.5 |
| D | 2 | 16 | 18068 | 64.29 | 922 | 937 | 266.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
